Acura ILX I facelift (2015-2018) relay holder c under-hood fuse/relay box Wiring diagrams
This page contains all the electrical diagrams for the component. relay holder c under-hood fuse/relay box, in which he is found in the car Acura ILX I facelift (2015-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram relay holder c under-hood fuse/relay box (1 of 2)
32 BIT MICROCOMPUTER + EEPROM 32 BIT MICROCOMPUTER + FLASH ROM
AIR CONDITIONING SYSTEM
AUTO
B-CAN H B-CAN
B-CAN L
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX 1
CENTER JUNCTION BOX 2
COMBINATION LIGHT SWITCH
COMPUTER DATA LINES SYSTEM
CONNECTOR
CRUISE LIGHTS DIMMING CIRCUIT
DIMMER/ FLASH-TO- PASS SWITCH
FOG LIGHT RELAY
FOG LIGHT SWITCH
FRONT FOG LIGHT IND
FUSE 12
FUSE 20
FUSE 23
FUSE 29
FUSE 5
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HEAD
HEADLIGHT SWITCH
HIGH BEAM IND
HOT AT ALL TIMES
LEFT FOG LIGHT
LEFT HEADLIGHT LOW BEAM RELAY
LEFT LED CONTROL UNIT ASSEMBLY
LIGHTS ON IND
LT BLU WIRE
LT GRN WIRE
MICU
OFF PARK
OPTIONAL
ORG/ WIRE
PASS
PNK WIRE
PPL
RED WIRE
RELAY ENERGIZED
RELAY HOLDER C UNDER-HOOD FUSE/RELAY BOX
RIGHT FOG LIGHT
RIGHT HEADLIGHT LOW BEAM RELAY
RIGHT LED CONTROL UNIT ASSEMBLY
SUNLIGHT SENSOR
TRANSCEIVER/
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
W/ COLOR MULTI-INFORMATION DISPLAY W/O COLOR MULTI-INFORMATION DISPLAY
WARNING DRIVE CIRCUIT
WHT WIRE
Go to component -> Headlights circuit -> RELAY HOLDER C UNDER-HOOD FUSE/RELAY BOX
Wiring diagram relay holder c under-hood fuse/relay box (2 of 2)
ANC/ ACTIVE SOUND CONTROL UNIT
AUDIO DISPLAY UNIT
AUDIO UNIT
AUDIO- NAVIGATION UNIT
BATTERY SENSOR
BLU WIRE
BRAKE LIGHT RELAY UNDER-DASH RELAY HOLDER B
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CENTER DISPLAY UNIT
CENTER JUNCTION BOX 1
CENTER JUNCTION BOX 2
DATA LINK CONNECTOR (DLC)
DAYTIME RUNNING LIGHT RELAY
FOG LIGHT RELAY
FROM FUSE 1-6 (DIAGRAM 1 OF 6)
FRONT HFL-ANC/ACTIVE SOUND CONTROL MICROPHONE
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 17
FUSE 18
FUSE 28
FUSE 29
GAUGE CONTROL MODULE
GRN WIRE
HAZARD WARNING SWITCH
HOME LINK UNIT
HORN RELAY
IGNITION COIL RELAY
INTERIOR LIGHT CUT RELAY UNDER-DASH RELAY HOLDER A
LT BLU WIRE
LT GRN WIRE
MICU
MULTI-PURPOSE CAMERA UNIT
PGM-FI SUB- RELAY
POWER SEAT CONTROL UNIT
POWER WINDOW MASTER SWITCH
RELAY HOLDER C INJECTOR RELAY
RELAY HOLDER C UNDER-HOOD FUSE/RELAY BOX
SUNLIGHT SENSOR
TELEMATICS CONTROL UNIT
UNDER-DASH FUSE/RELAY BOX
UNDER-DASH RELAY HOLDER B
UNDER-DASH RELAY HOLDER C
W/ CMBS
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 6) -> RELAY HOLDER C UNDER-HOOD FUSE/RELAY BOX
