Supplemental restraints circuit for Volvo XC90 II (2014-2019)

94/324 94/402 94/404 94/405 94/506 94/576 BATTERY ENERGY CONTROL MODULE (BECM) BLK WIRE BLU WIRE BLU/GRN WIRE BRAKE PEDAL DECOUPLING BRN WIRE BRN/GRN WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM DRIVER SIDE FRONT AIR BAG DRIVER'S SIDE KNEE FRONT AIR BAG DRIVER'S SIDE KNEE FRONT AIR BAG STAGE 2 ENGINE FUSE BOX FUSE 46 FUSE 52 GRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/VIO WIRE GRY/YEL WIRE LEFT FRONT IMPACT SENSOR NCA WIRE OCCUPANT WEIGHT SENSOR (OWS) ORG/ WIRE ORG/GRN WIRE PASSENGER'S SIDE FRONT AIR BAG PNK WIRE RED WIRE RELAY ENERGIZED RIGHT FRONT IMPACT SENSOR SEAT BELT TENSION SENSOR STEERING WHEEL MODULE (SWM) STEERING WHEEL) SUPPLEMENTAL RESTRAINT SYSTEM MODULE (SRS) VIO WIRE VIO/ORG WIRE WHT WIRE WHT/ORG WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/GRN WIRE YEL/ORG WIRE

94/402 94/504 94/505 94/506 94/519 BLK WIRE BLK/ORG WIRE BLK/VIO WIRE BLU WIRE BLU/GRN WIRE BLU/ORG WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE CENTRAL ELECTRONIC MODULE (CEM) COMPUTER DATA LINES SYSTEM FUSE 12 FUSE 20 FUSE 26 FUSE 32 GRN WIRE GRN/YEL WIRE GRY WIRE GRY/ORG WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ HOT W/ IGNITION EXTENDED RELAY ENERGIZED LEFT B-POST IMPACT SENSOR LEFT FRONT SIDE IMPACT PROTECTION LEFT INFLATABLE CURTAIN LEFT RESTRAINT MODULE ORG/ WIRE ORG/GRN WIRE REAR FUSE BOX RED WIRE RED/VIO WIRE RED/YEL WIRE RIGHT FRONT DOOR IMPACT SENSOR RIGHT FRONT SIDE IMPACT PROTECTION RIGHT RESTRAINT MODULE VIO WIRE VIO/GRN WIRE VIO/WHT WIRE WHT WIRE WHT/ORG WIRE YEL WIRE

94/503 94/506 94/518 94/531 BLK WIRE BLU/ORG WIRE BRN WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM GRN WIRE GRN/YEL WIRE GRY WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/YEL WIRE LEFT FRONT DOOR IMPACT SENSOR ORG/ WIRE ORG/GRN WIRE PASSENGER SIDE SEAT BELT BUCKLE SENSOR PASSENGER'S SIDE SEAT POSITION SENSOR RIGHT B-POST IMPACT SENSOR RIGHT FRONT SEAT BELT FORCE REDUCER VIO WIRE VIO/GRN WIRE WHT WIRE YEL WIRE

94/505 94/517 94/519 94/531 BLK WIRE BLU/ORG WIRE BRN WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/ORG WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER SIDE SEAT BELT BUCKLE SENSOR DRIVER SIDE SEAT POSITION SENSOR EXCEPT HYBRID GRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/YEL WIRE LEFT FRONT SEAT BELT FORCE REDUCER LEFT FRONT SHOULDER SEAT BELT PRETENSIONER MAIN BATTERY FUSE BOX ORG/ WIRE ORG/GRN WIRE RIGHT FRONT SHOULDER SEAT BELT PRETENSIONER RIGHT INFLATABLE CURTAIN SUPPLEMENTAL RESTRAINT SYSTEM MODULE (SRS) VIO WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/WHT WIRE WHT WIRE YEL WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/VIO WIRE
