Electric parking brake circuit for Volvo XC90 II (2014-2019)
Electric parking brake circuit
94/303
94/404
94/406
94/514
94/515
BLK WIRE
BLK/GRN WIRE
BLU/GRN WIRE
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CENTRAL ELECTRONIC MODULE (CEM)
COMPUTER DATA LINES SYSTEM
ENGINE FUSE BOX
FUSE 38
FUSE 43
FUSE 46
GRN/WHT WIRE
GRN/YEL WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
LEFT REAR PARKING BRAKE CALIPER MOTOR
PNK WIRE
RED WIRE
RED/WHT WIRE
RIGHT REAR PARKING BRAKE CALIPER MOTOR
START, BRAKE SWITCH MODULE (SBSM)
VEHICLE DYNAMICS DOMAIN MASTER (VDDM)
VIO WIRE
VIO/ORG WIRE
WHT/ORG WIRE
YEL/ORG WIRE
