Ground distribution circuit for Volvo XC90 II (2014-2019)

94/324 94/518 ACCELERATOR PEDAL SENSOR BATTERY BACKED-UP SOUNDER (BBS) BATTERY CONTROL SWITCH MODULE (BCSM) BATTERY ENERGY CONTROL MODULE (BECM) BATTERY MONITORING SENSOR (BMS) BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BLK/YEL WIRE BRAKE FLUID LEVEL SENSOR ENGINE FUSE BOX EXCEPT HYBRID EXTERIOR SOUND MODULE (ESM) HEADLIGHTS WASHER FLUID PUMP HIGH VOLTAGE BATTERY COOLING FAN HOOD LATCH LEFT HEADLIGHT UNIT LEFT HORN RADIATOR COOLING FAN RIGHT HEADLIGHT UNIT RIGHT HORN RIGHT REAR FOLDABLE HEADREST MOTOR RIGHT REAR PTC HEATER RIGHT WINDSHIELD WASHER HEATED NOZZLE TRANSMISSION ACTUATOR CONTROL MODULE (TACM) VEHICLE DYNAMICS DOMAIN MASTER (VDDM) WASHER FLUID LEVEL SENSOR WIPER MOTOR MODULE (WMM)

94/429 94/503 94/504 94/505 94/506 94/509 94/510 94/549 94/566 AUDIO CONTROL MODULE (AUD) BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BLU WIRE CENTER SECOND ROW SHOULDER SEAT BELT PRETENSIONER CENTRAL ELECTRONIC MODULE (CEM) DRIVER DOOR MODULE (DDM) DRIVER POWER SEAT MODULE (PSMD) ELECTRONIC GEAR SELECTOR MODULE (EGSM) EXCEPT HYBRID FRONT 12 V SOCKET FRONT TUNNEL CONSOLE ILLUMINATION LEFT FRONT SEAT HEATING MODULE (SHML) LEFT REAR DOOR MODULE (RDM) OCCUPANT SENSOR OCCUPANT WEIGHT SENSOR (OWS) PASSENGER DOOR MODULE (PDM) PASSENGER POWER SEAT MODULE (PSMP) REAR CONSOLE SWITCH MODULE (RCSM) REAR TUNNEL USB CHARGING HUB REAR WINDOW HEATER RIGHT FRONT SEAT HEATING MODULE (SHMR) RIGHT REAR DOOR MODULE (RDM) RIGHT RESTRAINT MODULE (RMR) START, BRAKE SWITCH MODULE (SBSM) TUNNEL CONSOLE STORAGE ILLUMINATION TUNNEL CUP HOLDER TUNNEL CONSOLE ILLUMINATION

94/517 94/521 94/527 94/553 94/558 94/565 94/598 94/604 A/C SHUT OFF VALVE AIR SUSPENSION COMPRESSOR BLK WIRE BLK/ORG WIRE BLU WIRE BRN WIRE DIFFERENTIAL ELECTRONIC MODULE (DEM) DRIVER SIDE TREADPLATE LED HIGH-MOUNTED BRAKE LIGHT IGNITION COIL, SPARK PLUG 1 IGNITION COIL, SPARK PLUG 2 IGNITION COIL, SPARK PLUG 3 IGNITION COIL, SPARK PLUG 4 LEFT LUGGAGE COMPARTMENT LAMP LEFT REAR FOLDABLE HEADREST MOTOR LEFT REAR PTC HEATER LEFT REAR SEAT BACKREST HEATER LEFT REAR SEAT HEATING MODULE (SHRL) LEFT REAR TAIL LIGHT LEFT REAR TREADPLATE LED LEFT RESTRAINT MODULE (RML) LEFT SIDE OBSTACLE DETECTION CONTROL MODULE (SODL) LICENSE PLATE UNIT ON-BOARD CHARGER MODULE (OBC) PASSENGER'S SIDE TREADPLATE LED REAR BLOWER MODULE REAR WIPER MOTOR RIGHT FRONT BACKREST FAN RIGHT FRONT SEAT BACKREST HEATER RIGHT FRONT SEAT CUSHION FAN RIGHT REAR FOOTWELL ILLUMINATION RIGHT REAR TREADPLATE LED RIGHT SEAT COMFORT MODULE RIGHT SEAT COMFORT PUMP

94/502 94/515 94/550 94/597 94/601 BLK WIRE BLK/WHT WIRE BRN WIRE ELECTRIC REAR AXLE DRIVE (ERAD) EXCEPT HYBRID EXHAUST SYSTEM ACTUATOR FOOT MOVEMENT DETECTION MODULE (FMDM) FUEL LID MOTOR FUEL PUMP MODULE FUEL TANK ISOLATION VALVE HIGH VOLTAGE COOLANT HEATER (HVCH) LEFT FRONT BACKREST FAN LEFT FRONT SEAT BACKREST HEATER LEFT FRONT SEAT CUSHION FAN LEFT REAR FOOTWELL ILLUMINATION LEFT SEAT COMFORT MODULE LEFT SEAT COMFORT PUMP LUGGAGE COMPARTMENT 12 V SOCKET POWER OPERATED TAILGATE MODULE (POT) POWER STEERING CONTROL MODULE (PSCM) RIGHT LUGGAGE COMPARTMENT LAMP RIGHT REAR TAIL LIGHT RIGHT SIDE OBSTACLE DETECTION CONTROL MODULE (SODR) SUPPORT BATTERY SUSPENSION MODULE (SUM) TAILGATE LUGGAGE COMPARTMENT LAMP TRUNK LID LOCK

94/319 94/403 94/410 94/701 94/702 AIR CONDITIONING COMPRESSOR MODULE (ACCM) AUXILIARY WATER PUMP BLK WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BRAKE PEDAL SENSOR CLIMATE CONTROL MODULE (CCM) DIAGNOSTIC SOCKET OBD II DRIVER SIDE INSTRUMENT PANEL ILLUMINATION DRIVER TRANSMISSION OIL PUMP ELECTRIC DRIVETRAIN COOLANT PUMP ENGINE CONTROL MODULE (ECM) FRONT LEFT FOOTWELL ILLUMINATION HIGH VOLTAGE BATTERY COOLANT FLUID PUMP HUMIDITY SENSOR INTERIOR REAR VIEW MIRROR MODULE (IRMM) LEFT CENTER VENT REGISTER THUMBWHEEL LED LEFT REAR OVERHEAD CONSOLE LEFT SUN VISOR MIRROR LAMP LEFT VENT REGISTER THUMBWHEEL LED OVERHEAD CONSOLE (OHC) PANORAMA ROOF MOTOR PANORAMA ROOF SUN BLIND MOTOR RIGHT REAR OVERHEAD CONSOLE RIGHT SUN VISOR MIRROR LAMP STEERING WHEEL (SWM) MODULE SUN SENSOR TRANSMISSION CONTROL MODULE (TCM)

94/403 94/408 94/409 ACTIVE SAFETY DOMAIN MASTER (ASDM) BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN WIRE CENTER CONSOLE DISPLAY (CCD) CENTER CONSOLE SWITCH MODULE (CCSM) CENTER FRONT INSTRUMENT PANEL ILLUMINATION DRIVER INFORMATION MODULE (DIM) FRONT BLOWER MOTOR UNIT FRONT RIGHT FOOTWELL ILLUMINATION GLOVE BOX ILLUMINATION LAMP GLOVE BOX LOCK MOTOR GRAPHICAL HEAD-UP DISPLAY (GHUD) HIGH VOLTAGE COOLANT HEATER (HVCH) IHU USB PORT INFOTAINMENT HEAD UNIT (IHU) MULTIBAND ANTENNA MODULE (MAM) PASSENGER'S SIDE FRONT AIR BAG PASSENGER'S SIDE INSTRUMENT PANEL ILLUMINATION RIGHT CENTER VENT REGISTER THUMBWHEEL LED RIGHT VENT REGISTER THUMBWHEEL LED VEHICLE CONNECTIVITY MODULE (VCM) WIDE ANGLE VISION MODULE (WAM)
