Electronic power steering circuit for Volvo XC90 II (2014-2019)
Electronic power steering circuit
94/322
BLK WIRE
BLU/GRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CENTRAL ELECTRONIC MODULE (CEM)
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL MODULE (ECM)
ENGINE FUSE BOX
EXCEPT HYBRID
FUSE 4
FUSE 46
FUSE 6
GRN/YEL WIRE
HOT AT ALL TIMES
HOT W/ IGNITION
POWER STEERING CONTROL MODULE (PSCM)
PRIMARY RELAY & FUSE BOX
PRIMARY RELAY & FUSE BOX 1
PRIMARY RELAY & FUSE BOX 3
RED WIRE
RED/WHT WIRE
VEHICLE DYNAMICS DOMAIN MASTER (VDDM)
VIO/GRN WIRE
VIO/WHT WIRE
WHT/GRN WIRE
