Volvo XC90 II (2014-2019) supercharger bypass actuator Wiring diagrams

This page contains all the electrical diagrams for the component. supercharger bypass actuator, in which he is found in the car Volvo XC90 II (2014-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram supercharger bypass actuator (1 of 3)

Wiring diagram supercharger bypass actuator for Volvo XC90 II (2014-2019) (1 of 3)

Get access

94/326 BLK WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/WHT WIRE BRN WIRE BRN/GRY WIRE BRN/WHT WIRE BRN/YEL WIRE ENGINE CONTROL MODULE (ECM) (FRONT LEFT SIDE OF ENGINE COMPT) ENGINE COOLING ELECTRIC THERMOSTAT EXHAUST SIDE VVT SOLENOID FUEL INJECTOR 4 GRN/VIO WIRE GRN/YEL WIRE GRY WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/YEL WIRE INLET SIDE VVT SOLENOID OIL LEVEL SENSOR ORG/ WIRE ORG/YEL WIRE SUPERCHARGER BYPASS ACTUATOR TURBO BYPASS VALVE VIO WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE WASTEGATE TURBO CONTROL VALVE WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/ORG WIRE YEL WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/VIO WIRE

Go to component -> Wiring diagram engine performance 2.0l turbo (4 of 6) -> SUPERCHARGER BYPASS ACTUATOR

Wiring diagram supercharger bypass actuator (2 of 3)

Wiring diagram supercharger bypass actuator for Volvo XC90 II (2014-2019) (2 of 3)

Get access

94/301 94/324 94/326 A/C COOLING SHUT OFF VALVE AIR PRESSURE, AIR TEMPERATURE SENSOR 1 BLK WIRE BLU WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/WHT WIRE BRN WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER COMPUTER DATA COOLING FANS DATA LINES ENGINE CONTROL MODULE (ECM) (FRONT LEFT SIDE OF ENGINE COMPT) FUEL QUANTITY CONTROL VALVE GRY/ORG WIRE GRY/WHT WIRE GRY/YEL WIRE HIGH VOLTAGE BATTERY COOLING BYPASS VALVE HIGH VOLTAGE COOLING SHUT OFF VALVE LINES SYSTEM MANIFOLD PRESSURE SENSOR (MAP) NCA WIRE OIL LEVEL SENSOR ORG/ WIRE ORG/GRN WIRE ORG/YEL WIRE SUPERCHARGER AIR PRESSURE SENSOR SUPERCHARGER BYPASS ACTUATOR SYSTEM VIO WIRE VIO/ORG WIRE VIO/WHT WIRE WHT WIRE WHT/GRN WIRE WHT/ORG WIRE YEL WIRE YEL/ORG WIRE

Go to component -> Wiring diagram engine performance 2.0l turbo hybrid (6 of 9) -> SUPERCHARGER BYPASS ACTUATOR
