Volvo XC90 II (2014-2019) middle lambda probe wiring diagram
This page shows the only wiring diagram for the component.middle lambda probe, which is found in the car Volvo XC90 II (2014-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
middle lambda probe wiring diagram (1 of 1)
BLK WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRN WIRE
BRN/YEL WIRE
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE OIL PUMP SOLENOID
EXHAUST SIDE VVT SOLENOID
FRONT LAMBDA PROBE
FUEL PRESSURE SENSOR (HIGH PRESSURE SIDE)
FUSE 33
GRN/YEL WIRE
GRY WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT W/ IGNITION EXTENDED RELAY ENERGIZED
INLET SIDE VVT SOLENOID
KNOCK SENSOR
MIDDLE LAMBDA PROBE
NCA WIRE
OIL PRESSURE, OIL TEMPERATURE SENSOR
ORG/ WIRE
ORG/GRN WIRE
REAR FUSE BOX
REAR LAMBDA PROBE
SUPERCHARGER CLUTCH
TURBO BYPASS VALVE
VIO WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WASTEGATE TURBO CONTROL VALVE
WHT WIRE
WHT/BRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 2.0l turbo hybrid (8 of 9) -> MIDDLE LAMBDA PROBE
