Volvo XC90 II (2014-2019) left dashboard air duck temperature sensor Wiring diagrams

94/301 94/403 94/404 94/701 A/C COOLING BYPASS VALVE BLK WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/GRY WIRE BRN/WHT WIRE CENTRAL ELECTRONIC MODULE (CEM) CENTRAL FUSE BOX CLIMATE CONTROL MODULE (CCM) COMPUTER DATA LINES SYSTEM FRONT BLOWER MOTOR UNIT FUSE 18 GRN WIRE GRY/ORG WIRE HOT AT ALL TIMES HUMIDITY SENSOR LEFT DASHBOARD AIR DUCK TEMPERATURE SENSOR RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT DASHBOARD AIR DUCK TEMPERATURE SENSOR RIGHT END OF DASH) ROOF CONSOLE SEATS SYSTEM VIO WIRE VIO/GRN WIRE VIO/WHT WIRE WHT WIRE YEL WIRE

94/301 94/402 94/403 94/404 94/405 94/406 94/408 94/421 94/701 A/C SHUTOFF VALVE BLK WIRE BLK/YEL WIRE BLU/GRY WIRE BRN WIRE BRN/GRY WIRE BRN/WHT WIRE CENTRAL FUSE BOX CLIMATE CONTROL MODULE (CCM) COMPUTER DATA LINES SYSTEM FUSE 18 FUSE 32 FUSE 8 GRN WIRE GRN/YEL WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/YEL WIRE HIGH VOLTAGE COOLANT HEATER (HVCH) HOT AT ALL TIMES HOT W/ HUMIDITY SENSOR LEFT DASHBOARD AIR DUCK TEMPERATURE SENSOR LEFT FLOOR CONSOLE TEMPERATURE SENSOR LEFT REAR FLOOR AIR DUCK TEMPERATURE SENSOR ORG/GRN WIRE RED WIRE RED/GRN WIRE RIGHT DASHBOARD AIR DUCK TEMPERATURE SENSOR RIGHT END OF DASH) RIGHT REAR FLOOR AIR DUCK TEMPERATURE SENSOR ROOF CONSOLE SEATS SYSTEM STEERING WHEEL MODULE (SWM) SUN SENSOR VIO WIRE VIO/GRN WIRE VIO/WHT WIRE WHT WIRE WHT/GRN WIRE YEL WIRE
