Volvo XC90 II (2014-2019) exhaust side camshaft position sensor Wiring diagrams

This page contains all the electrical diagrams for the component. exhaust side camshaft position sensor, in which he is found in the car Volvo XC90 II (2014-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram exhaust side camshaft position sensor (1 of 3)

Wiring diagram exhaust side camshaft position sensor for Volvo XC90 II (2014-2019) (1 of 3)

Get access

94/317 AIR PRESSURE, AIR TEMPERATURE SENSOR 1 BLK WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/ORG WIRE BRN WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE COOLING FANS SYSTEM CRANKSHAFT POSITION SENSOR ENGINE CONTROL MODULE (ECM) ENGINE COOLANT TEMPERATURE SENSOR EXHAUST SIDE CAMSHAFT POSITION SENSOR GRN WIRE GRY WIRE GRY/VIO WIRE GRY/YEL WIRE HIGH PRESSURE SIDE FUEL PRESSURE SENSOR IGNITION COIL, SPARK PLUG 1 IGNITION COIL, SPARK PLUG 2 IGNITION COIL, SPARK PLUG 3 IGNITION COIL, SPARK PLUG 4 INLET SIDE CAMSHAFT POSITION SENSOR KNOCK SENSOR MASS AIRFLOW SENSOR (MAF) NCA WIRE OIL PRESSURE, OIL TEMPERATURE SENSOR ORG/GRN WIRE VIO WIRE VIO/GRN WIRE VIO/ORG WIRE VIO/WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/ORG WIRE YEL WIRE YEL/VIO WIRE

Go to component -> Wiring diagram engine performance 2.0l turbo (6 of 6) -> EXHAUST SIDE CAMSHAFT POSITION SENSOR

Wiring diagram exhaust side camshaft position sensor (2 of 3)

Wiring diagram exhaust side camshaft position sensor for Volvo XC90 II (2014-2019) (2 of 3)

Get access

94/301 BLK WIRE BLU WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/WHT WIRE BRN WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE COOLING FANS SYSTEM CRANKSHAFT POSITION SENSOR ENGINE CONTROL MODULE (ECM) ENGINE FUSE BOX EXHAUST SIDE CAMSHAFT POSITION SENSOR FUSE 61 FUSE 62 FUSE 63 FUSE 64 FUSE 67 FUSE 69 FUSE 70 GRN WIRE GRY WIRE GRY/BRN WIRE GRY/VIO WIRE GRY/YEL WIRE HOT AT ALL TIMES INLET SIDE CAMSHAFT POSITION SENSOR MASS AIRFLOW SENSOR (MAF) ORG/GRN WIRE THROTTLE UNIT VIO WIRE VIO/GRN WIRE VIO/ORG WIRE VIO/WHT WIRE WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/ORG WIRE YEL WIRE YEL/VIO WIRE

Go to component -> Wiring diagram engine performance 2.0l turbo hybrid (9 of 9) -> EXHAUST SIDE CAMSHAFT POSITION SENSOR
