Volvo XC90 II (2014-2019) center front expansion tank level sensor Wiring diagram
This page shows the only wiring diagram for the component.center front expansion tank level sensor, which is found in the car Volvo XC90 II (2014-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram center front expansion tank level sensor (1 of 1)
11 94/301
31 94/301
94/301
94/303
94/323
94/324
94/511
94/515
ACCELERATOR PEDAL SENSOR
BLK WIRE
BLK/WHT WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRY WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CENTER FRONT EXPANSION TANK LEVEL SENSOR
CENTRAL FUSE BOX
COOLING FANS SYSTEM
ELECTRICAL DRIVETRAIN COOLANT TEMPERATURE SENSOR
ENGINE CONTROL MODULE (ECM)
ENGINE FUSE BOX
FUEL PUMP (TOP OF TANK)
FUEL PUMP MODULE (REAR OF TANK)
FUSE 43
FUSE 44
FUSE 46
FUSE 54
FUSE 56
GRN/WHT WIRE
GRY WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HIGH VOLTAGE BATTERY COOLING EXTERNAL TEMPERATURE SENSOR
HOT AT ALL TIMES
HOT W/ IGNITION
PNK WIRE
RED WIRE
TRANSMISSIONS SYSTEM
VIO WIRE
VIO/ORG WIRE
WHT WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL WIRE
YEL/GRY WIRE
YEL/ORG WIRE
Go to component -> Wiring diagram engine performance 2.0l turbo hybrid (1 of 9) -> CENTER FRONT EXPANSION TANK LEVEL SENSOR
