Volvo XC90 I facelift (2006-2014) vio Wiring diagrams

BLK WIRE CENTRAL ELECTRONIC MODULE (BEHIND LEFT SIDE OF DASH) FRONT FUSE FUSE 11 HOT AT ALL TIMES MAIN FUSES (NEXT TO BATTERY, IN CARGO COMPT) OUTLET PORTABLE NAVIGATION SYSTEM RED WIRE VIO WIRE

54/1300 54/1400 BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM FRONT PARKING ASSISTANCE SENSOR 5 (W/ ACCESSORIES) FRONT PARKING ASSISTANCE SENSOR 6 (W/ ACCESSORIES) FRONT PARKING ASSISTANCE SENSOR 7 (W/ ACCESSORIES) FRONT PARKING ASSISTANCE SENSOR 8 (W/ ACCESSORIES) FUSE (NEXT TO BATTERY, IN CARGO COMPT) GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES MAIN FUSES PARKING ASSISTANCE MODULE (AT LEFT SIDE OF CARGO AREA) REAR ELECTRONIC MODULE REAR PARKING ASSISTANCE SENSOR 1 REAR PARKING ASSISTANCE SENSOR 2 REAR PARKING ASSISTANCE SENSOR 3 REAR PARKING ASSISTANCE SENSOR 4 RED WIRE VIO WIRE WHT WIRE YEL WIRE

15 54/25 16 54/25 BACKREST SWITCH BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE CEM CENTRAL ELECTRONIC MODULE (BEHIND LEFT SIDE OF DASH) DOWN FORW FORW BACK FORWARD/ BACKWARD SWITCH FRONT EDGE UP/DOWN SWITCH FUSE FUSE 28 GRN WIRE GRN/BLK WIRE GRN/RED WIRE HOT AT ALL TIMES HOT AT ALL TIMES MAIN FUSE FUSES (NEXT TO BATTERY, IN CARGO COMPT.) PASSENGER COMPARTMENT FUSE BOX (AT LEFT END OF DASH) POWER PASSENGER SEAT SWITCH UNIT REAR EDGE UP/DOWN SWITCH RED WIRE STOP LOGIC UP BACK UP DOWN VIO WIRE VIO/BLK WIRE YEL WIRE YEL/BLK WIRE

6 12 54/134 AUDIO MODULE BLK WIRE BLU WIRE BLU/RED WIRE BLUETOOTH PHONE MODULE CARGO COMPARTMENT CENTRAL ELECTRONIC MODULE COMFORT SYSTEM SEATS RELAY, LEFT, RIGHT REAR SEAT HEATER RELAY DATA LINK CONNECTOR, STEERING WHEEL MODULE, LIGHT SWITCH MODULE DRIVER/ PASSENGER DOOR MODULE DVD PLAYER/ CONTROL MODULE, TV RECEIVER EB CENTRAL ELECTRONIC MODULE (BEHIND LEFT SIDE OF DASH) FUSE 11 FROM BATTERY (DIAGRAM 1 OF 2) FUSE FUSE 8 FUSE FUSE FUSE FUSE FUSE GRY/RED WIRE IGNITION SWITCH LOCK LOCK OFF MAIN FUSES (NEXT TO BATTERY, IN CARGO COMPT) ON LOCK KEY IN IGNITION SWITCH OFF ON LOCK OFF ON OFF OUTLET PASSENGER COMPARTMENT FAN CONTROL MODULE PASSENGER COMPARTMENT FUSE BOX PASSENGER POWER SEAT POWER MODULE SEAT SWITCH UNIT PHONE MODULE PORTABLE NAVIGATION SYSTEM REAR ELECTRONIC MODULE REAR ELECTRONIC MODULE (AT LEFT REAR CORNER OF CARGO COMPT) RED WIRE RED/BLK WIRE RED/WHT WIRE SUNROOF MODULE, UPPER ELECTRONIC MODULE UPPER ELECTRONIC MODULE VIO WIRE VIO/WHT WIRE YEL WIRE YEL/WHT WIRE

2 3 DL PNK WIRE 54/10 54/11 54/43 8 7 6 CL BLK WIRE BLL BLU WIRE BLU/WHT WIRE BRN WIRE CLIMATE CONTROL MODULE COMPUTER DATA LINES SYSTEM DRIVER/PASSENGER DOOR MODULE (DDM/PDM) (IN DRIVER'S DOOR) FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES KEY KEY UNLOCK LEFT FRONT DOOR LOCK UNIT (REAR LEFT FRONT DOOR) LOCK PASSENGER COMPARTMENT FUSE BOX FUSE (AT LEFT END OF DASH) PASSENGER/DRIVER DOOR MODULE (PDM/DDM) (IN FRONT PASSENGER'S DOOR) PCL CHILD SAFETY LOCK SWITCH PNK PNK 1 2 WIRE PNK WIRE RED WIRE RIGHT FRONT DOOR LOCK UNIT (REAR OF RIGHT FRONT DOOR) TRUNK LID/ TAILGATE PRIVATE LOCK SWITCH UNLOCK UPPER ELECTRONIC MODULE (REARWARD OF ROOF CONSOLE) VIO WIRE VIO/WHT WIRE WHT WIRE YEL WIRE

10 11 54/21 11 54/43 12 54/20 3 7 PCL 4 54/21 5 54/20 54/20 54/21 54/43 6 54/43 7 54/21 7 54/43 BLK WIRE BLL BLU WIRE BLU/BLK WIRE CENTRAL ELECTRONIC MODULE (CEM) (BEHIND LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM FUEL FILLER FLAP LOCK MOTOR (RIGHT SIDE OF CARGO COMPT, BEHIND CARPET) FUSE FUSE FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES IGNITION SWITCH KEY IN KEY IN IGNITION LEFT REAR DOOR DEADLOCK RELAY (IN LEFT REAR DOOR) LEFT REAR DOOR LOCK UNIT (REAR OF LEFT REAR DOOR) LEFT REAR DOOR POWER WINDOW SWITCH MAIN FUSES (NEXT TO BATTERY, IN CARGO COMPT) PCL PNK PNK 1 2 WIRE PNK PNK WIRE PNK WIRE REAR ELECTRONIC MODULE (REM) (AT LEFT REAR CORNER OF CARGO COMPT) RED WIRE RIGHT REAR DOOR DEADLOCK RELAY (IN RIGHT REAR DOOR) RIGHT REAR DOOR LOCK UNIT (REAR OF RIGHT REAR DOOR) RIGHT REAR DOOR POWER WINDOW SWITCH TAILGATE LOCK UNIT (CENTER OF TAILGATE) VIO WIRE VIO/WHT WIRE WHT WIRE YEL WIRE

54/13 BLU WIRE BRN WIRE BWD CEILING LIGHT SWITCH UNIT COMPUTER DATA LINES SYSTEM FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES LT BLU WIRE PASSENGER COMPARTMENT FUSE BOX (AT LEFT END OF DASH) PNK 5 6 7 8 9 SOLID STATE WIRE PNK WIRE POWER SUNROOF SWITCH RED WIRE SUNROOF MODULE (SRM) (FORWARD OF SUNROOF OPENING) SUNROOF MOTOR (FORWARD OF SUNROOF OPENING) UPPER ELECTRONIC MODULE (UEM) (REARWARD OF ROOF CONSOLE) VIO WIRE VIO/WHT WIRE WHT WIRE YEL WIRE

1 7 8 54/43 12 54/20 12 54/21 54/10 54/11 54/20 6 5 8 54/21 BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM DRIVER/PASSENGER DOOR MODULE (DDM/PDM) (IN DRIVER'S DOOR) FUSE FUSE 10 FUSE 9 GRN WIRE GRN/BRN WIRE HOT AT ALL TIMES HOT AT ALL TIMES MAIN FUSES FUSE (NEXT TO BATTERY, IN CARGO COMPT) LEFT REAR DOOR POWER WINDOW SWITCH LEFT REAR POWER WINDOW MOTOR (IN LEFT REAR DOOR) PASSENGER COMPARTMENT FUSE BOX (AT LEFT END OF DASH) PASSENGER/DRIVER DOOR MODULE (PDM/DDM) (IN FRONT PASSENGER'S DOOR) REAR ELECTRONIC MODULE (AT LEFT REAR CORNER OF CARGO COMPT) RED WIRE RED/BLK WIRE RIGHT REAR DOOR POWER WINDOW SWITCH RIGHT REAR POWER WINDOW MOTOR (IN RIGHT REAR DOOR) SOLID STATE VIO WIRE WHT WIRE YEL WIRE

5 6 PNK WIRE BLK WIRE BLU WIRE BRN WIRE CAMERA CENTRAL ELECTRONIC MODULE (BEHIND LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES MULTIMEDIA DISPLAY NCA WIRE ORG/ WIRE PNK (NOT USED) WIRE PNK WIRE REAR ELECTRONIC MODULE (AT LEFT REAR CORNER OF CARGO COMPT) RED WIRE SOUND SYSTEMS VIO WIRE WHT WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE CENTRAL ELECTRONIC MODULE (BEHIND LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM FM SUB FUSE FUSE 5 GRN WIRE GRY WIRE HOT AT ALL TIMES INTEGRATED AUDIO MODULE (IN CENTER OF DASH) MAIN FUSES (NEXT TO BATTERY, IN CARGO COMPT) MULTIMEDIA DISPLAY MULTIMEDIA MODULE (UNDER DRIVER SEAT) NCA WIRE ORG/ WIRE PASSENGER COMPARTMENT FUSE BOX (AT LEFT END OF DASH) PNK WIRE RED WIRE RIGHT HAND REAR WINDOW ANTENNA RIGHT WINDOW ANTENNA AMPLIFIER 1 (ABOVE RIGHT REAR WINDOW) SOUND SYSTEMS VIO WIRE VIO/WHT WIRE WHT WIRE YEL WIRE
