Volvo XC90 I facelift (2006-2014) low high ls can Wiring diagram
This page shows the only wiring diagram for the component.low high ls can, which is found in the car Volvo XC90 I facelift (2006-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low high ls can (1 of 1)
13 21 PNK PNK WIRE
22 54/3.1
4 3 54/10
54/11
54/13
54/16
54/25
54/3.1
54/74
6 5 54/13
6 54/9
ALTERNATOR CONTROL MODULE (ACM) (ON ALTERNATOR)
AWD W/ HCM AWD W/O HCM 1 2 3 4 5 6
BRAKE CONTROL MODULE (BCM) (AT LEFT REAR CORNER OF ENGINE COMPARTMENT)
BRN WIRE
CENTRAL ELECTRONIC MODULE (BEHIND LEFT SIDE OF DASH)
COMBUSTION PREHEATER MODULE (CPM) (LEFT FRONT OF ENGINE COMPT)
CONTACT REEL (TOP OF STEERING COLUMN)
DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH)
DIFFERENTIAL ELECTRONIC MODULE (AT REAR DIFFERENTIAL)
DRIVER/PASSENGER DOOR MODULE (DDM/PDM) (IN DRIVER'S DOOR)
FUSE FUSE BOX (AT LEFT END OF DASH)
GRN WIRE
GRN/WHT WIRE
HEADLIGHT CONTROL MODULE (HCM)
HOT AT ALL TIMES
LEFT CAMERA MODULE
LEFT POWER EXTERIOR REARVIEW MIRROR (IN LEFT REARVIEW MIRROR)
LIGHTS SWITCH UNIT (LSM)
LOW HIGH HS CAN
LOW HIGH LS CAN
NCA WIRE
OCCUPANT WEIGHT SENSOR (OWS) (UNDER FRONT PASSENGER'S SEAT)
PASSENGER COMPARTMENT)
PNK 54/3.1 WIRE
PNK PNK WIRE
PNK WIRE
RAIN SENSOR MODULE (RSM) (TOP CENTER OF WINDSHIELD)
REARVIEW MIRROR)
RED WIRE
RIGHT CAMERA MODULE
RIGHT POWER EXTERIOR
SIREN CONTROL MODULE (SCM) (RIGHT FRONT WHEELWELL)
STEERING ANGLE SENSOR MODULE
STEERING WHEEL MODULE (SWM) (IN STEERING WHEEL)
SUN ROOF MODULE (SRM) (FORWARD OF SUN ROOF OPENING)
SUPPLEMENTAL RESTRAINT SYSTEM MODULE (SRS) (UNDER CENTER CONSOLE)
UPPER ELECTRONIC MODULE (UEM) (REARWARD OF ROOF CONSOLE)
W/ HCM AWD
W/O SUNROOF
WHT WIRE
Go to component -> Computer data lines circuit (1 of 2) -> LOW HIGH LS CAN
