Volvo XC90 I facelift (2006-2014) left back massage pump Wiring diagram
This page shows the only wiring diagram for the component.left back massage pump, which is found in the car Volvo XC90 I facelift (2006-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left back massage pump (1 of 1)
BLK WIRE
BLU/PNK WIRE
CARGO COMPARTMENT FUSE HOLDER (IN REAR OF CARGO COMPT)
FUSE FUSE
GRN/RED WIRE
HOT AT ALL TIMES FUSE FUSE
INTERFACE CONNECTOR
LEFT BACK MASSAGE CONTROL MODULE
LEFT BACK MASSAGE PUMP
LEFT SEAT BACKREST VENTILATION FAN
MAIN FUSES (NEXT TO BATTERY, IN CARGO COMPT)
NCA WIRE
PNK WIRE
PNK/BLK WIRE
REAR ELECTRONIC MODULE FUSE (AT LEFT REAR CORNER OF CARGO COMPT)
RED WIRE
RIGHT BACK MASSAGE CONTROL MODULE
RIGHT BACK MASSAGE PUMP
RIGHT SEAT BACKREST VENTILATION FAN
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLK YEL WIRE
Go to component -> Heated massage seat circuit -> LEFT BACK MASSAGE PUMP
