Volvo XC90 I facelift (2006-2014) automatic transmission program selector Wiring diagram
This page shows the only wiring diagram for the component.automatic transmission program selector, which is found in the car Volvo XC90 I facelift (2006-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram automatic transmission program selector (1 of 1)
26 54/3.1
5 54/3.1
54/57.1
54/74
7 54/57.1
A/T FLUID TEMP SENSOR
AUTOMATIC TRANSMISSION
AUTOMATIC TRANSMISSION PROGRAM SELECTOR
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAKE CONTROL MODULE (BCM) (AT LEFT REAR CORNER OF ENGINE COMPT)
BRN WIRE
CENTRAL ELECTRONIC MODULE (CEM) (BEHIND LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL MODULE (ECM) (LEFT REAR OF ENGINE COMPT)
FUSE
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES MAIN FUSES (NEXT TO BATTERY IN CARGO COMPT) FUSE
INPUT SPEED SENSOR
LINEAR PRESSURE
LOCK-UP SOLENOID SHIFT SOLENOID 1
NCA WIRE
OUTPUT SPEED SENSOR
RED WIRE
SHIFT INTERLOCK SYSTEM
SHIFT LEVER)
SHIFT SOLENOID 2
THROTTLE SOLENOID
TRANSMISSION CONTROL MODULE (TCM) (RIGHT FRONT OF ENGINE COMPT)
VIO/WHT WIRE
WHT WIRE
YEL WIRE
