Car Wiring Diagrams for Warning systems circuit for Volvo XC90 I (2002-2006)

BRAKE CONTROL MODULE (AT LEFT REAR CORNER OF ENGINE COMPARTMENT) BRN/GRY WIRE BRN/PNK WIRE CENTRAL ELECTRONIC MODULE COMBINED INFORMATION PANEL DIM COMPUTER DATA LINES SYSTEM GRN WIRE HOT AT ALL TIMES IGNITION SWITCH KEY-IN IGNITION SWITCH LEFT FRONT ABS SENSOR (BEHIND LEFT FRONT WHEEL, ON SPINDLE/ HUB ASSEMBLY) LEFT SEAT BELT LATCH SWITCH (ON LEFT SEAT BELT BUCKLE) NCA WIRE ORG/BLK WIRE PASSENGER SEAT WEIGHT SENSOR RIGHT FRONT ABS SENSOR (BEHIND RIGHT FRONT WHEEL, ON SPINDLE/ HUB ASSEMBLY) RIGHT SEAT BELT LATCH SWITCH (ON RIGHT SEAT BELT BUCKLE) STEERING WHEEL MODULE VIO WIRE WHT WIRE YEL WIRE YEL/GRY WIRE YEL/RED WIRE
