Electronic suspension circuit for Volvo XC70 II facelift (2013-2016)

10 74/519 11 74/519 15-FEED FEED REAR RELAY 16 15 14 74/511 4 3 5 74/513 5 6 74/519 7 74/519 74/503 74/511 74/513 74/518 74/519 8 74/519 9 74/519 BLK WIRE BLK/GRN WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/RED WIRE BRN WIRE CEM CENTRAL ELECTRONIC MODULE (BEHIND RIGHT END OF DASH) COMPUTER DATA LINES SYSTEM CONTINUOUSLY CONTROLLED DAMPING SWITCH UNIT (CCD) DISTRIBUTION BOX (RIGHT SIDE OF DASH) FUSE FUSE FUSE GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/VIO WIRE GRY WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/YEL WIRE HEIGHT SENSOR HOT AT ALL TIMES LEFT FRONT FOUR-C ACCELERATION SENSOR (BEHIND LEFT FRONT BUMPER) LEFT FRONT FOUR-C SHOCK ABSORBER (IN LEFT FRONT WHEELWELL) LEFT FRONT SUSPENSION HEIGHT SENSOR (IN LEFT FRONT WHEELWELL) LEFT REAR FOUR-C ACCELERATION SENSOR (LEFT REAR CORNER OF LUGGAGE COMPT) LEFT REAR FOUR-C SHOCK ABSORBER (IN LEFT REAR WHEELWELL) ORG/ WIRE PASSENGER COMPARTMENT) RED WIRE RED/BLK WIRE RED/BLU WIRE RIGHT FRONT FOUR-C ACCELERATION SENSOR (BEHIND RIGHT SIDE OF FRONT BUMPER) RIGHT FRONT FOUR-C SHOCK ABSORBER (IN RIGHT FRONT WHEELWELL) RIGHT FRONT SUSPENSION HEIGHT SENSOR (IN RIGHT FRONT WHEELWELL) RIGHT REAR FOUR-C SHOCK ABSORBER (IN RIGHT REAR WHEELWELL) RIGHT REAR SUSPENSION HEIGHT SENSOR (IN RIGHT REAR WHEELWELL) SUSPENSION MODULE (SUM) (BEHIND CENTER OF REAR SEATS) VIO WIRE VIO/BRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/RED WIRE VIO/WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE YEL/VIO WIRE
