Volvo XC70 II facelift (2013-2016) w/ bluetooth hands free w/o bluetooth hands free Wiring diagram
This page shows the only wiring diagram for the component.w/ bluetooth hands free w/o bluetooth hands free, which is found in the car Volvo XC70 II facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ bluetooth hands free w/o bluetooth hands free (1 of 1)
1 3 2 4 74/403
14 13 74/412 1 8 74/412 10 3
2 74/405
21 74/409
74/409
74/419
74/420
9 10 (NOT USED)
ANT PWR
ANTENNA
AUX 2 B - AUX 2 B + AUX 2 L - AUX 2 L + 12 13
AUX L + AUX R + AUX R -
AUXILIARY EQUIPMENT INPUT
BLK WIRE
BLK/GRY WIRE
BLU/GRN WIRE
BLU/RED WIRE
BRN WIRE
CIRCUIT
DATA
FUSE
GRN WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY/YEL WIRE
GSM/GPS/RDAR ANTENNA (CENTER REAR OF ROOF)
HOT AT ALL TIMES
INTEGRATED AUDIO MODULE
LVDS- LVDS+ SHIELD
MIC + MIC -
MICROPHONE (IN OVERHEAD CONSOLE)
MOST DATA BUS CIRCUIT
NCA WIRE
ORG/ WIRE
PWR GND
REAR SEAT ENTERTAINMENT
RED WIRE
RED/BLK WIRE
SHIELD
STEERING WHEEL MODULE (SWM) (IN STEERING COLUMN)
USB-PORT (W/O ACCESSORY)
V-BUS
VBATT
VIO WIRE
VIO/RED WIRE
W/ BLUETOOTH HANDS FREE W/O BLUETOOTH HANDS FREE
W/ SENSUS CONNECTED TOUCH W/O SENSUS CONNECTED TOUCH
WHT WIRE
WINDOW ANTENNA AMPLIFIER (AT LEFT "C" PILLAR)
YEL/RED WIRE
Go to component -> Radio circuit, premium (3 of 3) -> W/ BLUETOOTH HANDS FREE W/O BLUETOOTH HANDS FREE
