Volvo XC70 II facelift (2013-2016) solar sensor, twilight sensor, indicator alarm (top center Wiring diagram
This page shows the only wiring diagram for the component.solar sensor, twilight sensor, indicator alarm (top center, which is found in the car Volvo XC70 II facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram solar sensor, twilight sensor, indicator alarm (top center (1 of 1)
15- FEED RELAY
2 1 PNK WIRE
22 74/401 (UNDER DRIVER'S DOOR SILL) HEATED REAR WINDOW/REARVIEW MIRRORS SWITCH
74/401
74/417
74/504
AIR QUALITY SENSOR (AQS)
AUXILIARY LIGHTS SWITCH
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLU WIRE
BRN/VIO WIRE
CENTRAL ELECTRONIC MODULE
CENTRAL ELECTRONIC MODULE (CEM) (BEHIND RIGHT END OF DASH)
CLIMATE CONTROL MODULE (CENTER OF DASH)
CLIMATE CONTROL SYSTEM
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM 1 2
DEFROSTER DAMPER MOTOR MODULE (DMM)
ENGINE COMPARTMENT DISTRIBUTION BOX (AT LEFT SIDE OF ENGINE COMPT, FORWARD OF
EVAPORATOR TEMPERATURE SENSOR
FLOOR/VENTILATION DAMPER MOTOR MODULE (DMM)
FUSE
FUSE FUSE
FUSE FUSE FUSE FUSE STRUT TOWER)
GRN WIRE
GRY/BLK WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT SIDE TEMPERATURE DAMPER MOTOR MODULE (DMM)
OF DASH)
PTC ELEMENT (BEHIND CENTER OF DASH)
RECIRCULATION DAMPER MOTOR MODULE (DMM)
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RIGHT SIDE TEMPERATURE DAMPER MOTOR MODULE (DMM)
SOLAR SENSOR, TWILIGHT SENSOR, INDICATOR ALARM (TOP CENTER
SOLID STATE
VIO/BLK WIRE
VIO/GRN WIRE
VIO/ORG WIRE
WHT/GRN WIRE
YEL WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit (1 of 2) -> SOLAR SENSOR, TWILIGHT SENSOR, INDICATOR ALARM (TOP CENTER
