Volvo XC70 II facelift (2013-2016) shield gnd data+ data- vbus 4 3 2 1 Wiring diagram
This page shows the only wiring diagram for the component.shield gnd data+ data- vbus 4 3 2 1, which is found in the car Volvo XC70 II facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram shield gnd data+ data- vbus 4 3 2 1 (1 of 1)
1 2 LVDS- LVDS+ SHIELD
74/401
ACCESSORY CONNECTIVITY UNIT (ACU) (W/ SENSUS CONNECTED TOUCH)
ACCESSORY USB UNIT (AUU) (BEHIND LEFT SIDE OF DASH)
AUX 2 L-
AUX 2 R-
BLK WIRE
BLK/GRY WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DATA
GPS ANT
GPS ANTENNA
GRN/BRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY/ORG WIRE
GRY/YEL WIRE
INFOTAINMENT CONTROL MODULE (CENTER OF DASH)
LIN
LVDS
MIC SCR
MIC SIG
MICROPHONE (IN OVERHEAD CONSOLE)
MOST DATA BUS CIRCUIT
NCA WIRE
ORG/ WIRE
REAR SEAT ENTERTAINMENT CIRCUIT
RED WIRE
SHIELD
SHIELD GND DATA+ DATA- VBUS 4 3 2 1
VBUS
VIO WIRE
VIO/ORG WIRE
VIO/RED WIRE
W/ SENSUS CONNECTED TOUCH W/O SENSUS CONNECTED TOUCH
WHT WIRE
YEL/RED WIRE
Go to component -> Radio circuit, premium (2 of 3) -> SHIELD GND DATA+ DATA- VBUS 4 3 2 1
