Volvo XC70 II facelift (2013-2016) right front suspension height sensor Wiring diagram
This page shows the only wiring diagram for the component.right front suspension height sensor, which is found in the car Volvo XC70 II facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front suspension height sensor (1 of 1)
11 8 74/519 6 74/519
15- FEED RELAY
16 15 14 74/511
5 4 3 74/513
74/519
9 11 10 74/512
BLK/GRN WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRN/BLU WIRE
CENTRAL ELECTRONIC MODULE (CEM)
CENTRAL ELECTRONIC MODULE (CEM) (BEHIND RIGHT END OF DASH)
COMPUTER DATA LINES SYSTEM
CONTACT REEL (TOP OF STEERING COLUMN)
ELECTRONIC SUSPENSION SYSTEM
ENGINE COMPARTMENT DISTRIBUTION BOX (AT LEFT SIDE OF ENGINE COMPT, FORWARD OF
FUSE
FUSE FUSE STRUT TOWER)
GRN/BLK WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT FRONT LAMP HOUSING
LEFT FRONT SUSPENSION HEIGHT SENSOR (W FOUR-C) (IN LEFT FRONT WHEELWELL)
LEFT HAND HEADLIGHT LEVEL ADJUSTMENT MOTOR
LEFT REAR SUSPENSION HEIGHT SENSOR (W/ FOUR-C) (IN LEFT REAR WHEELWELL)
RED/BLK WIRE
RED/BLU WIRE
RIGHT FRONT LAMP HOUSING
RIGHT FRONT SUSPENSION HEIGHT SENSOR
RIGHT FRONT SUSPENSION HEIGHT SENSOR (W/ FOUR-C) (IN RIGHT FRONT WHEELWELL)
RIGHT HAND HEADLIGHT LEVEL ADJUSTMENT MOTOR
RIGHT REAR SUSPENSION HEIGHT SENSOR (W/ FOUR-C) (IN RIGHT REAR WHEELWELL)
RIGHT REAR SUSPENSION HEIGHT SENSOR (W/O FOUR-C) (IN RIGHT REAR WHEELWELL)
SOLAR SENSOR, TWILIGHT SENSOR, INDICATOR ALARM (TOP CENTER OF DASH)
STEERING ANGLE SENSOR
STEERING WHEEL ANGLE SENSOR MODULE (SAS)
STEERING WHEEL MODULE (SWM) (IN STEERING COLUMN)
SUSPENSION MODULE (SUM) (BEHIND CENTER OF REAR SEATS)
VIO/WHT WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Headlamps leveling circuit -> RIGHT FRONT SUSPENSION HEIGHT SENSOR
