Volvo XC70 II facelift (2013-2016) front view camera circuit Wiring diagram
This page shows the only wiring diagram for the component.front view camera circuit, which is found in the car Volvo XC70 II facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front view camera circuit (1 of 1)
6 7 8 9 10 PNK ID TMC TX TMC RX TMC GND TMC 2 4 5 WIRE
74/501
74/504
BLK WIRE
BLU WIRE
CENTRAL ELECTRONIC MODULE (BEHIND CEM RIGHT END OF DASH)
COMFORT FUNCTIONS RELAY
ENGINE COMPARTMENT DISTRIBUTION BOX
FRONT
FRONT VIEW CAMERA CIRCUIT
FUSE
FUSE FUSE (AT LEFT SIDE OF ENGINE COMPARTMENT, FORWARD OF STRUT TOWER)
GND TMC
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
ID TMC
NCA WIRE
ORG/ WIRE
OUTLET
PASSENGER COMPARTMENT DISTRIBUTION BOX (RIGHT SIDE OF DASH)
PORTABLE NAVIGATION SYSTEM
POWER DISTRIBUTION SYSTEM
PWR TMC
RED WIRE
RED/VIO WIRE
RX TMC
TRAFFIC MESSAGE CHANNEL MODULE (TMC)
TX TMC
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit -> FRONT VIEW CAMERA CIRCUIT
