Instrument illumination circuit for Volvo XC70 II (2007-2013)

20 74/507 74/411 74/501 74/507 74/508 74/509 74/510 BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BLU/BLK WIRE BLU/RED WIRE BRN/VIO WIRE CEM CENTRAL ELECTRONIC MODULE (BEHIND RIGHT END OF DASH) COMPUTER DATA LINES SYSTEM COURTESY LAMPS CIRCUIT DRIVER DOOR MODULE (IN DRIVER'S FRONT DOOR) DRIVER'S DOOR CENTRAL LOCKING SYSTEM SWITCH FUSE GEAR SELECTOR MODULE (CENTER CONSOLE) GRN/BLK WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/RED WIRE GRN/VIO WIRE GRN/WHT WIRE GRY/ORG WIRE HOT AT ALL TIMES LEFT REAR DOOR MODULE (IN LEFT REAR DOOR) LEFT REAR DOOR POWER WINDOW SWITCH LIGHT SWITCH MODULE PASSENGER COMPARTMENT FUSE BOX PASSENGER DOOR CENTRAL LOCKING SYSTEM SWITCH PASSENGER DOOR MODULE (IN PASSENGER'S FRONT DOOR) PASSENGER DOOR POWER WINDOW SWITCH RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RIGHT REAR DOOR MODULE (IN RIGHT REAR DOOR) RIGHT REAR DOOR POWER WINDOW SWITCH STEERING WHEEL MODULE (IN STEERING COLUMN) VIO WIRE VIO/ORG WIRE VIO/RED WIRE W/KEYLESS ENTRY YEL WIRE YEL/RED WIRE
