Wiring diagram engine performance 3.2l for Volvo XC70 II (2007-2013)

BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE ENGINE CONTROL MODULE (ECM) (LEFT REAR OF ENGINE COMPT) FRONT KNOCK SENSOR (TOP FRONT OF ENGINE) FUEL PRESSURE, TEMPERATURE SENSOR (LEFT FRONT OF ENGINE) GRN WIRE GRN/BLK WIRE GRN/BRN WIRE GRN/RED WIRE GRN/VIO WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/VIO WIRE INTAKE MANIFOLD PRESSURE SENSOR (IN INTAKE MANIFOLD) NCA WIRE OIL LEVEL SENSOR (IN OIL COOLER) REAR KNOCK SENSOR (AT TOP REAR OF ENGINE) VIO WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/ORG WIRE WHT/BRN WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE YEL/VIO WIRE

BLK/ORG WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE CAPACITOR (TOP OF ENGINE, NEAR OIL FILLER) GRN WIRE GRN/BRN WIRE GRN/VIO WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/VIO WIRE NCA WIRE SPARK PLUGS, IGNITION COILS (TOP OF CYLINDER HEAD COVER) VARIABLE VALVE LIFTER (FRONT PLANE) VARIABLE VALVE LIFTER (REAR PLANE) VIO WIRE VIO/BLK WIRE VIO/BRN WIRE WHT/ORG WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRY WIRE YEL/RED WIRE YEL/VIO WIRE

AIR CONDITIONING SYSTEM BLK/YEL WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE COMPUTER DATA LINES SYSTEM ELECTRONIC THROTTLE ACTUATOR (ON THROTTLE BODY) ENGINE CONTROL MODULE (ECM) (LEFT REAR OF ENGINE COMPT) ENGINE MANAGEMENT SYSTEM MAIN RELAY FUSE FUSE FUSE GRN/BLU WIRE GRN/BRN WIRE GRN/VIO WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/VIO WIRE GRY/YEL WIRE HOT AT ALL TIMES LIN RED WIRE RED/VIO WIRE VIO WIRE VIO/BLK WIRE VIO/BRN WIRE VIO/GRY WIRE WHT WIRE WHT/ORG WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE

15- FEED RELAY 74/301 74/504 ACCELERATOR PEDAL SENSOR (TOP OF ACCELERATOR PEDAL ASSEMBLY) BLK WIRE BLK/GRN WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE CEM CENTRAL ELECTRONIC MODULE (CEM) (BEHIND RIGHT END OF DASH) FUSE FUSE FUSE GRN/BLU WIRE GRN/ORG WIRE GRN/VIO WIRE GRN/WHT WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/VIO WIRE GRY/YEL WIRE HOT AT ALL TIMES INJECTORS (TOP OF ENGINE) RED/VIO WIRE RED/WHT WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE WHT WIRE YEL/ORG WIRE

11 9 10 74/411 18 74/504 29 74/301 3 74/514 74/301 74/504 74/511 74/512 9 8 22 74/403 AIR CONDITIONING SYSTEM AIR CONDITIONING SYSTEM STARTING/CHARGING SYSTEM BLK/WHT WIRE BLK/YEL WIRE BLU GRN/ORG WIRE BLU WIRE BLU/BLK WIRE BLU/GRY WIRE BLU/WHT WIRE BRN WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM ENGINE CONTROL MODULE (ECM) (LEFT REAR OF ENGINE COMPT) FUEL LEAKAGE CONTROL PUMP (UNDER REAR OF VEHICLE, FORWARD OF FUEL TANK) FUEL PUMP (TOP OF FUEL TANK) FUEL PUMP CONTROL MODULE (ON FUEL TANK ASSEMBLY) GRN/BLK WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/ORG BLU WIRE GRN/ORG WIRE GRN/RED WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/VIO WIRE INSTRUMENT CLUSTER SYSTEM NCA WIRE RED/VIO WIRE RED/WHT WIRE STARTING/CHARGING SYSTEM VIO/BRN WIRE VIO/ORG WIRE VIO/WHT WIRE WHT WIRE WHT/BRN WIRE YEL WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE
