Tire pressure monitoring circuit for Volvo XC60 I (2008-2013)

BLK/BLU WIRE BLK/WHT WIRE CEM CENTRAL ELECTRONIC MODULE (CEM) (BEHIND RIGHT END OF DASH) COMPUTER DATA LINES SYSTEM DRIVER INFORMATION ENGINE COMPARTMENT DISTRIBUTION FUSE FUSE BOX (LEFT SIDE OF ENGINE COMPT) FUSE DISTRIBUTION BOX (RIGHT END OF DASH) GRN/RED WIRE GRY/BRN WIRE GRY/ORG WIRE HOT AT ALL TIMES KEYLESS VEHICLE MODULE (KVM) LEFT FRONT TIRE PRESSURE SENSOR (IN LEFT FRONT WHEEL ASSEMBLY) LEFT REAR TIRE PRESSURE SENSOR (IN LEFT REAR WHEEL ASSEMBLY) MODULE PASSENGER COMPARTMENT) RED/BLK WIRE RED/BLU WIRE RED/BRN WIRE REMOTE KEYLESS ENTRY (RKE) REMOTE RECEIVER MODULE (RRX) (CENTER REAR OF ROOF) RIGHT FRONT TIRE PRESSURE SENSOR (IN RIGHT FRONT WHEEL ASSEMBLY) RIGHT REAR TIRE PRESSURE SENSOR (IN RIGHT REAR WHEEL ASSEMBLY) VIO/ORG WIRE W/ KVM W/O KVM
