Most data bus circuit for Volvo XC60 I (2008-2013)
Most data bus circuit (1 of 4)
74/404
74/529
AUDIO MODULE (AUD) (UNDER FRONT PASSENGER'S SEAT)
BLUETOOTH PHONE MODULE (BPM) (UNDER RIGHT SIDE OF DASH)
DIGITAL AUDIO BROADCAST MODULE (DABM) (CENTER FRONT OF LUGGAGE COMPT)
INFOTAINMENT CONTROL MODULE
INTEGRATED AUDIO MODULE (IAM) (CENTER OF DASH)
MULTIMEDIA MODULE (MMM) (LEFT REAR OF LUGGAGE COMPT)
ORG/ WIRE
PHONE MODULE (PHM) (BEHIND RIGHT SIDE OF DASH)
REMOTE DIGITAL AUDIO RECEIVER (RDAR) (CENTER FRONT OF LUGGAGE COMPT)
STANDARD
SUBWOOFER MODULE (SUB) (LEFT SIDE OF LUGGAGE COMPT)
W/ REMOTE DIGITAL RECEIVER DIGITAL AUDIO BROADCAST, BLUETOOTH PHONE MODULE
W/ REMOTE DIGITAL RECEIVER, DIGITAL AUDIO BROADCAST PHONE AUDIO MODULE
Most data bus circuit (2 of 4)
74/404
74/529
AUDIO MODULE (AUD) (UNDER FRONT PASSENGER'S SEAT)
BLUETOOTH PHONE MODULE (BPM) (UNDER RIGHT SIDE OF DASH)
INFOTAINMENT CONTROL MODULE
INTEGRATED AUDIO MODULE (IAM) (CENTER OF DASH)
MULTIMEDIA MODULE (MMM) (LEFT REAR OF LUGGAGE COMPT)
ORG/ WIRE
PHONE MODULE (PHM) (BEHIND RIGHT SIDE OF DASH)
W/O REMOTE DIGITAL RECEIVER, DIGITAL AUDIO BROADCAST PHONE AUDIO MODULE
W/O REMOTE DIGITAL RECEIVER, DIGITAL AUDIO BROADCAST, BLUETOOTH PHONE MODULE
Most data bus circuit (3 of 4)
2 74/529
74/404
74/529
AUDIO MODULE (AUD) (UNDER FRONT PASSENGER'S SEAT)
BLUETOOTH PHONE MODULE (BPM) (UNDER RIGHT SIDE OF DASH)
DIGITAL AUDIO BROADCAST MODULE (DABM) (CENTER FRONT OF
INFOTAINMENT CONTROL MODULE
INTEGRATED AUDIO MODULE (IAM) (CENTER OF DASH)
LUGGAGE COMPT)
MULTIMEDIA MODULE (MMM) (LEFT REAR OF LUGGAGE COMPT)
ORG/ WIRE
PHONE MODULE (PHM) (BEHIND RIGHT SIDE OF DASH)
SUBWOOFER MODULE (SUB) (LEFT SIDE OF
W/ DIGITAL AUDIO BROADCAST, BLUETOOTH PHONE MODULE
W/ DIGITAL AUDIO BROADCAST, PHONE MODULE
Most data bus circuit (4 of 4)
2 74/529
74/404
74/529
AUDIO MODULE (AUD) (UNDER FRONT PASSENGER'S SEAT)
BLUETOOTH PHONE MODULE (BPM) (UNDER RIGHT SIDE OF DASH)
INFOTAINMENT CONTROL MODULE
INTEGRATED AUDIO MODULE (IAM) (CENTER OF DASH)
LUGGAGE COMPT)
MULTIMEDIA MODULE (MMM) (LEFT REAR OF LUGGAGE COMPT)
ORG/ WIRE
PHONE MODULE (PHM) (BEHIND RIGHT SIDE OF DASH)
REMOTE DIGITAL AUDIO RECEIVER (RDAR) (CENTER FRONT OF LUGGAGE COMPT)
SUBWOOFER MODULE (SUB) (LEFT SIDE OF
W/ REMOTE DIGITAL RECEIVER, BLUETOOTH PHONE MODULE
W/ REMOTE DIGITAL RECEIVER, PHONE MODULE
