Car Wiring Diagrams for Anti-theft circuit for Volvo XC40 I facelift (2022-2024)

94/503 94/509 BLK WIRE BLK/VIO WIRE BRN WIRE BRN/GRY WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CENTRAL FUSE BOX COMPUTER DATA LINES SYSTEM DRIVER DOOR MODULE (DDM) DRIVER DOOR SWITCH CLUSTER (DDS) FUSE 10 FUSE 11 FUSE 13 FUSE 20 FUSE 9 GRN WIRE GRN/YEL WIRE GRY WIRE GRY/ORG WIRE GRY/VIO WIRE HOT AT ALL TIMES LEFT EXTERNAL MIRROR GLASS LEFT FRONT DOOR LATCH LEFT FRONT OUTER DOOR HANDLE LEFT REAR CENTRAL LOCKING SWITCH LEFT REAR DOOR LATCH LEFT REAR DOOR MODULE (RDM) LEFT REAR OUTER DOOR HANDLE RED WIRE RED/YEL WIRE VIO WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/WHT WIRE WHT/GRN WIRE YEL WIRE YEL/VIO WIRE

94/403 94/409 94/434 94/503 94/504 94/509 94/510 BATTERY BACKED-UP SOUNDER (BBS) BLK WIRE BLK/VIO WIRE BLK/YEL WIRE BLU WIRE BRN/GRY WIRE BRN/VIO WIRE BRN/YEL WIRE CENTRAL ELECTRONIC MODULE (CEM) ELECTRIC ENGINE FUSE BOX EXCEPT ELECTRIC FUEL LID MOTOR (AT FUEL FLAP) FUSE 30 GRN WIRE GRY WIRE GRY/VIO WIRE HOOD LATCH HORNS SYSTEM HOT AT ALL TIMES INTERIOR MOTION SENSOR (IMS) LEFT FRONT KEYLESS VEHICLE ANTENNA LUGGAGE COMPARTMENT KEYLESS VEHICLE ANTENNA MULTIBAND ANTENNA MODULE (MAM) NCA WIRE ORG/GRN WIRE ORG/YEL WIRE PASSENGER COMPARTMENT KEYLESS VEHICLE ANTENNA RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT KEYLESS VEHICLE ANTENNA RIGHT REAR OUTER DOOR HANDLE STEERING WHEEL MODULE (SWM) SUN SENSOR VIO WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE WHT/GRN WIRE WHT/ORG WIRE YEL WIRE YEL/BLK WIRE YEL/ORG WIRE YEL/VIO WIRE YEL/WHT WIRE

94/409 94/504 94/510 BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/GRY WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CENTER CONSOLE SWITCH MODULE (CCSM) GRN/YEL WIRE GRY/VIO WIRE ORG/BLK WIRE PASSENGER DOOR MODULE (PDM) RED WIRE RIGHT EXTERNAL MIRROR GLASS RIGHT FRONT CENTRAL LOCKING SWITCH RIGHT FRONT DOOR LATCH RIGHT FRONT OUTER DOOR HANDLE RIGHT REAR CENTRAL LOCKING SWITCH RIGHT REAR DOOR LATCH RIGHT REAR DOOR MODULE (RDM) VIO WIRE VIO/GRN WIRE VIO/ORG WIRE WHT/GRN WIRE YEL WIRE YEL/ORG WIRE
