Volvo XC40 I facelift (2022-2024) right inflatable curtain Wiring diagram
This page shows the only wiring diagram for the component.right inflatable curtain, which is found in the car Volvo XC40 I facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right inflatable curtain (1 of 1)
94/503
94/504
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BRN/ORG WIRE
CAPACITIVE OCCUPANT SENSOR (COS)
DRIVER SIDE SHOULDER SEAT BELT PRETENSIONER
GRN WIRE
GRY WIRE
GRY/VIO WIRE
GRY/YEL WIRE
LEFT B-POST IMPACT SENSOR
LEFT FRONT DOOR IMPACT SENSOR
LEFT INFLATABLE CURTAIN
NCA WIRE
NOT USED
ORG/ WIRE
ORG/GRN WIRE
PASSENGER SIDE SHOULDER SEAT BELT PRETENSIONER
RIGHT B-POST IMPACT SENSOR
RIGHT FRONT DOOR IMPACT SENSOR
RIGHT INFLATABLE CURTAIN
VEHICLE CONNECTIVITY MODULE (VCM)
VIO WIRE
VIO/GRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
YEL/ORG WIRE
Go to component -> Supplemental restraints circuit (3 of 4) -> RIGHT INFLATABLE CURTAIN
