Volvo XC40 I facelift (2022-2024) right front outer door handle Wiring diagrams
This page contains all the electrical diagrams for the component. right front outer door handle, in which he is found in the car Volvo XC40 I facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right front outer door handle (1 of 2)
94/409
94/504
94/510
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRY WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CENTER CONSOLE SWITCH MODULE (CCSM)
GRN/YEL WIRE
GRY/VIO WIRE
ORG/BLK WIRE
PASSENGER DOOR MODULE (PDM)
RED WIRE
RIGHT EXTERNAL MIRROR GLASS
RIGHT FRONT CENTRAL LOCKING SWITCH
RIGHT FRONT DOOR LATCH
RIGHT FRONT OUTER DOOR HANDLE
RIGHT REAR CENTRAL LOCKING SWITCH
RIGHT REAR DOOR LATCH
RIGHT REAR DOOR MODULE (RDM)
VIO WIRE
VIO/GRN WIRE
VIO/ORG WIRE
WHT/GRN WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Anti-theft circuit (3 of 3) -> RIGHT FRONT OUTER DOOR HANDLE
Wiring diagram right front outer door handle (2 of 2)
94/409
94/504
94/510
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRY WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CENTER CONSOLE SWITCH MODULE (CCSM)
GRN/YEL WIRE
GRY/VIO WIRE
ORG/BLK WIRE
PASSENGER DOOR MODULE (PDM)
RED WIRE
RIGHT EXTERNAL MIRROR GLASS
RIGHT FRONT CENTRAL LOCKING SWITCH
RIGHT FRONT DOOR LATCH
RIGHT FRONT OUTER DOOR HANDLE
RIGHT REAR CENTRAL LOCKING SWITCH
RIGHT REAR DOOR LATCH
RIGHT REAR DOOR MODULE (RDM)
VIO WIRE
VIO/GRN WIRE
VIO/ORG WIRE
WHT/GRN WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Power door locks circuit (3 of 3) -> RIGHT FRONT OUTER DOOR HANDLE
