Volvo XC40 I facelift (2022-2024) passenger's side window control switch Wiring diagram
This page shows the only wiring diagram for the component.passenger's side window control switch, which is found in the car Volvo XC40 I facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger's side window control switch (1 of 1)
94/503
94/504
94/509
94/510
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/VIO WIRE
BRN/YEL WIRE
CENTRAL FUSE BOX
DRIVER DOOR MODULE (DDM)
DRIVER DOOR SWITCH CLUSTER (DDS)
FUSE 10
FUSE 11
FUSE 13
FUSE 9
GRN WIRE
GRN/YEL WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INTERIOR
LEFT REAR DOOR MODULE (RDM)
LEFT REAR WINDOW CONTROL SWITCH
LIGHTS SYSTEM
PASSENGER DOOR MODULE (PDM)
PASSENGER'S SIDE WINDOW CONTROL SWITCH
RED WIRE
RIGHT REAR DOOR MODULE (RDM)
RIGHT REAR WINDOW CONTROL SWITCH
WHT/GRN WIRE
Go to component -> Power windows circuit -> PASSENGER'S SIDE WINDOW CONTROL SWITCH
