Volvo XC40 I facelift (2022-2024) engine fuse box Wiring diagrams

94/303 94/516 BLK WIRE BLU WIRE BRN/GRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM ENGINE FUSE BOX EXTERIOR SOUND MODULE (ESM) FUSE 17 GRY/YEL WIRE HOT W/ IGNITION 15 RELAY ENERGIZED REAR EXTERIOR SOUND SPEAKER YEL/VIO WIRE

94/403 94/409 94/434 94/503 94/504 94/509 94/510 BATTERY BACKED-UP SOUNDER (BBS) BLK WIRE BLK/VIO WIRE BLK/YEL WIRE BLU WIRE BRN/GRY WIRE BRN/VIO WIRE BRN/YEL WIRE CENTRAL ELECTRONIC MODULE (CEM) ELECTRIC ENGINE FUSE BOX EXCEPT ELECTRIC FUEL LID MOTOR (AT FUEL FLAP) FUSE 30 GRN WIRE GRY WIRE GRY/VIO WIRE HOOD LATCH HORNS SYSTEM HOT AT ALL TIMES INTERIOR MOTION SENSOR (IMS) LEFT FRONT KEYLESS VEHICLE ANTENNA LUGGAGE COMPARTMENT KEYLESS VEHICLE ANTENNA MULTIBAND ANTENNA MODULE (MAM) NCA WIRE ORG/GRN WIRE ORG/YEL WIRE PASSENGER COMPARTMENT KEYLESS VEHICLE ANTENNA RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT KEYLESS VEHICLE ANTENNA RIGHT REAR OUTER DOOR HANDLE STEERING WHEEL MODULE (SWM) SUN SENSOR VIO WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE WHT/GRN WIRE WHT/ORG WIRE YEL WIRE YEL/BLK WIRE YEL/ORG WIRE YEL/VIO WIRE YEL/WHT WIRE

94/301 94/304 94/305 94/514 ANTI-LOCK BRAKES SYSTEM BLK WIRE BLK/VIO WIRE BLU WIRE BLU/GRN WIRE BLU/GRY WIRE BRAKE PEDAL SWITCH BRN WIRE BRN/GRN WIRE BRN/YEL WIRE CENTRAL ELECTRONIC MODULE (CEM) COMPUTER DATA LINES SYSTEM DCA DCAS DCB DCBS ELECTRIC REAR AXLE DRIVE (ERAD) (REAR MOTOR COMPT) ENGINE FUSE BOX FUSE 16 FUSE 22 FUSE 28 FUSE 48 GRN/VIO WIRE GRN/YEL WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/YEL WIRE HIGH VOLTAGE BATTERY (COMPLETE) HOT AT ALL TIMES HOT W/ HFF RELAY ENERGIZED HOT W/ IGNITION 15 RELAY ENERGIZED INVERTER ELECTRIC REAR AXLE DRIVE MODULE (IEM) NCA WIRE ON-BOARD CHARGER MODULE (OBC) ORG/ WIRE PNK WIRE RED WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE YEL WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/VIO WIRE YEL/WHT WIRE

30 94/301 94/303 94/434 BLK WIRE BLK/VIO WIRE BLK/YEL WIRE BLU/GRN WIRE BRAKE PEDAL SWITCH BRN WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CENTRAL ELECTRONIC MODULE (CEM) CENTRAL FUSE BOX COMPUTER DATA LINES SYSTEM ELECTRONIC GEAR SELECTOR MODULE (EGSM) ENGINE FUSE BOX FUSE 16 FUSE 22 FUSE 24 FUSE 25 GRN WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT W/ IGNITION 15 RELAY ENERGIZED LEFT FRONT WHEEL SPEED SENSOR RED WIRE RED/GRN WIRE RIGHT FRONT WHEEL SPEED SENSOR TRANSMISSION CONTROL MODULE (TCM) VIO/GRN WIRE VIO/WHT WIRE WHT WIRE WHT/GRN WIRE

19 94/304 24 94/304 94/303 94/403 94/701 BLK WIRE BLK/VIO WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/WHT WIRE BRN/YEL WIRE CENTRAL ELECTRONIC MODULE (CEM) CENTRAL FUSE BOX COMPUTER DATA LINES SYSTEM ENGINE FUSE BOX FRONT WINDOWS WASHER PUMP RELAY FUSE 2 FUSE 31 FUSE 55 FUSE 56 FUSE 83 GRY WIRE GRY/VIO WIRE HEADLAMP WASHER PUMP RELAY HEADLIGHTS WASHER FLUID PUMP HOT AT ALL TIMES HOT W/ BATTERY SAVER RELAY ENERGIZED INTERIOR REAR VIEW MIRROR MODULE (IRMM) POWER DISTRIBUTION SYSTEM RAIN, LIGHT SENSOR (RLSM) REAR WINDOWS WASHER PUMP RELAY RED WIRE WASHER FLUID LEVEL SENSOR WHT WIRE WHT/ORG WIRE WINDOW WASHER PUMP WIPER MOTOR MODULE (WMM) YEL/BLK WIRE

94/301 94/305 94/514 AIR CONDITIONING COMPRESSOR MODULE A (ACCA) BLK WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/WHT WIRE CENTRAL ELECTRONIC MODULE (CEM) EFCM RELAY ELECTRIC ELECTRIC DRIVETRAIN COOLANT PUMP ELECTRICAL EXPANSION VALVE (EXV) ENGINE CONTROL MODULE (ECM) ENGINE FUSE BOX ENGINE SYSTEM RELAY FROM CENTRAL FUSE BOX (DIAGRAM 5 OF 8) FROM MAIN BATTERY FUSE BOX (DIAGRAM 1 OF 8) FUSE FUSE 20 FUSE 29 FUSE 3 FUSE 38 FUSE 46 FUSE 47 FUSE 48 FUSE 49 FUSE 50 FUSE 54 GRY WIRE HEADLAMPS LED RELAY HFF RELAY HIGH VOLTAGE BATTERY (COMPLETE) HIGH VOLTAGE BATTERY COOLANT FLUID PUMP HIGH VOLTAGE COOLANT HEATER A (HVHA) HORN RELAY INVERTER ELECTRIC REAR AXLE DRIVE MODULE (IEM) INVERTER HIGH VOLTAGE FRONT AXLE (IHFA) NCA WIRE OUTSIDE HEAT EXCHANGER VALVE (OHXV) REAR WIPER RELAY RED WIRE RED/WHT WIRE SUPPORT BATTERY SUPPORT BATTERY FUSE TO ENGINE FUSE BOX (DIAGRAM 3 OF 8) TO ENGINE FUSE BOX (DIAGRAM 4 OF 8) TO FUSE 41 (DIAGRAM 3 OF 8)

94/301 94/303 94/304 94/322 94/323 94/404 94/434 94/506 ACCELERATOR PEDAL SENSOR BLU WIRE BLU/GRN WIRE BLU/GRY WIRE BRN WIRE CAPACITIVE OCCUPANT SENSOR (COS) CENTRAL ELECTRONIC MODULE (CEM) ELECTRIC ELECTRONIC GEAR SELECTOR MODULE (EGSM) ENGINE CONTROL MODULE (ECM) ENGINE FUSE BOX EXCEPT ELECTRIC EXTERIOR SOUND MODULE (ESM) FROM ENGINE FUSE BOX (DIAGRAM 2 OF 8) FUSE 12 FUSE 13 FUSE 14 FUSE 15 FUSE 16 FUSE 17 FUSE 41 FUSE 42 IGNITION 15 RELAY LEFT HEADLIGHT UNIT POWER STEERING CONTROL MODULE (PSCM) RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT HEADLIGHT UNIT SUPPLEMENTAL RESTRAINT SYSTEM MODULE (SRS) TO POWER OUTLET RELAY (DIAGRAM 4 OF 8) TRAILER MODULE TRANSMISSION CONTROL MODULE (TCM)

94/301 94/303 94/304 94/350 94/434 94/505 94/514 BATTERY BACKED-UP SOUNDER (BBS) BLK WIRE BLK/VIO WIRE BLU/BRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRAKE PEDAL SWITCH CENTRAL ELECTRONIC MODULE (CEM) ELECTRIC ENGINE CONTROL MODULE (ECM) ENGINE FUSE BOX EXCEPT ELECTRIC FROM ENGINE FUSE BOX (DIAGRAM 2 OF 8) FROM IGNITION 15 RELAY (DIAGRAM 3 OF 8) FUSE 1 FUSE 2 FUSE 22 FUSE 23 FUSE 24 FUSE 25 FUSE 26 FUSE 28 FUSE 30 FUSE 31 FUSE 32 FUSE 33 FUSE 35 FUSE 39 FUSE 4 FUSE 44 FUSE 57 GRY WIRE HIGH VOLTAGE BATTERY (COMPLETE) INVERTER HIGH VOLTAGE FRONT AXLE (IHFA) LEFT SEAT MODULE (SML) MID VOLTAGE CONVERTER MODULE (MVCM) N/A POWER OUTLET RELAY REAR TUNNEL USB CHARGING HUB RED WIRE RED/GRN WIRE RED/WHT WIRE TRANSMISSION CONTROL MODULE (TCM) WIPER MOTOR MODULE (WMM)

94/403 94/409 94/434 94/503 94/504 94/509 94/510 BATTERY BACKED-UP SOUNDER (BBS) BLK WIRE BLK/VIO WIRE BLK/YEL WIRE BLU WIRE BRN/GRY WIRE BRN/VIO WIRE BRN/YEL WIRE CENTRAL ELECTRONIC MODULE (CEM) ELECTRIC ENGINE FUSE BOX EXCEPT ELECTRIC FUEL LID MOTOR (AT FUEL FLAP) FUSE 30 GRN WIRE GRY WIRE GRY/VIO WIRE HOOD LATCH HORNS SYSTEM HOT AT ALL TIMES INTERIOR MOTION SENSOR (IMS) LEFT FRONT KEYLESS VEHICLE ANTENNA LUGGAGE COMPARTMENT KEYLESS VEHICLE ANTENNA MULTIBAND ANTENNA MODULE (MAM) NCA WIRE ORG/GRN WIRE ORG/YEL WIRE PASSENGER COMPARTMENT KEYLESS VEHICLE ANTENNA RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT KEYLESS VEHICLE ANTENNA RIGHT REAR OUTER DOOR HANDLE STEERING WHEEL MODULE (SWM) SUN SENSOR VIO WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE WHT/GRN WIRE WHT/ORG WIRE YEL WIRE YEL/BLK WIRE YEL/ORG WIRE YEL/VIO WIRE YEL/WHT WIRE

94/303 94/304 94/604 BLK WIRE BLK/VIO WIRE BLK/YEL WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/WHT WIRE BRN/YEL WIRE CENTRAL ELECTRONIC MODULE (CEM) CENTRAL FUSE BOX COMPUTER DATA LINES SYSTEM ENGINE FUSE BOX FRONT WINDOWS WASHER PUMP RELAY FUSE 2 FUSE 20 FUSE 56 FUSE 80 FUSE 83 GRY WIRE GRY/VIO WIRE HOT AT ALL TIMES HOT W/ BATTERY SAVER RELAY ENERGIZED REAR WINDOWS WASHER PUMP RELAY REAR WIPER MOTOR REAR WIPER RELAY RED WIRE WASHER FLUID LEVEL SENSOR WINDOW WASHER PUMP YEL WIRE
