Volvo XC40 I facelift (2022-2024) driver side seat position sensor Wiring diagram
This page shows the only wiring diagram for the component.driver side seat position sensor, which is found in the car Volvo XC40 I facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side seat position sensor (1 of 1)
94/304
94/505
94/506
94/516
BLK WIRE
BLU/ORG WIRE
BRN WIRE
BRN/GRN WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
DRIVER SIDE SEAT BELT BUCKLE SENSOR
DRIVER SIDE SEAT BELT FORCE REDUCER
DRIVER SIDE SEAT POSITION SENSOR
ELECTRIC
EXCEPT ELECTRIC
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HIGH VOLTAGE BATTERY (COMPLETE)
LEFT "C" PILLAR)
LEFT FRONT IMPACT SENSOR
LEFT FRONT SIDE IMPACT PROTECTION
MID VOLTAGE BATTERY MODULE (MVBM)
NCA WIRE
ORG/ WIRE
ORG/GRN WIRE
ORG/GRY WIRE
ORG/YEL WIRE
PASSENGER SIDE SEAT BELT BUCKLE SENSOR
PASSENGER SIDE SEAT BELT FORCE REDUCER
PNK WIRE
RIGHT FRONT IMPACT SENSOR
RIGHT FRONT SIDE IMPACT PROTECTION
SUPPLEMENTAL RESTRAINT SYSTEM MODULE (SRS)
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/WHT WIRE
WHT WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/GRN WIRE
YEL/ORG WIRE
Go to component -> Supplemental restraints circuit (4 of 4) -> DRIVER SIDE SEAT POSITION SENSOR
