Volvo XC40 I facelift (2022-2024) air inlet temperature sensor Wiring diagram
This page shows the only wiring diagram for the component.air inlet temperature sensor, which is found in the car Volvo XC40 I facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram air inlet temperature sensor (1 of 1)
94/301
94/303
94/514
A/C PRESSURE SENSOR
AIR INLET TEMPERATURE SENSOR
BLK/VIO WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CENTRAL FUSE BOX
CHARGE AIR DUCT PRESSURE SENSOR
ENGINE FUSE BOX
FUEL PUMP RELAY
FUSE 15
FUSE 16
FUSE 22
FUSE 26
FUSE 28
FUSE 3
FUSE 50
FUSE 51
GRN/BRN WIRE
GRN/GRY WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ IGNITION
LOW PRESSURE SIDE FUEL PRESSURE, TEMPERATURE SENSOR
MANIFOLD PRESSURE SENSOR (MAP)
MASS AIR FLOW SENSOR (MAF)
ORG/ WIRE
ORG/GRN WIRE
RED WIRE
RED/YEL WIRE
RIGHT SIDE OF RADIATOR)
VIO WIRE
VIO/BRN WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRY WIRE
YEL/ORG WIRE
Go to component -> Wiring diagram engine performance 2.0l turbo (6 of 7) -> AIR INLET TEMPERATURE SENSOR
