Volvo XC40 I facelift (2022-2024) 94/306 94/303 Wiring diagram
This page shows the only wiring diagram for the component.94/306 94/303, which is found in the car Volvo XC40 I facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 94/306 94/303 (1 of 1)
94/303
94/304
94/305
94/306 94/303
94/514
94/516
BLK/VIO WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CENTRAL FUSE BOX
COMPUTER DATA LINES SYSTEM
ELECTRIC
ENGINE CONTROLS SYSTEM
ENGINE FUSE BOX
EXCEPT ELECTRIC
FUSE 16
FUSE 23
GRN WIRE
GRN/YEL WIRE
GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ IGNITION 15 RELAY ENERGIZED
LEFT FRONT WHEEL SUSPENSION POSITION SENSOR
LEFT REAR WHEEL SUSPENSION POSITION SENSOR
ORG/BLU WIRE
ORG/GRN WIRE
ORG/WHT WIRE
PNK WIRE
RED WIRE
RIGHT FRONT EXPANSION TANK LEVEL SENSOR
TRANSMISSIONS SYSTEM
VIO WIRE
VIO/WHT WIRE
WHT WIRE
WHT/GRN WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Electronic suspension circuit -> 94/306 94/303
