Volvo V70 II facelift (2004-2007) Computer data lines circuit
Computer data lines circuit (1 of 2)
13 21 PNK PNK WIRE
ALTERNATOR (LEFT SIDE OF ENGINE)
BEHIND GEAR SELECTOR LEVER)
BRAKE CONTROL MODULE (BCM) (AT LEFT REAR CORNER OF ENGINE COMPT)
BRN WIRE
CENTRAL ELECTRONIC MODULE (BEHIND LEFT SIDE OF DASH)
COMBUSTION PREHEATER MODULE (CPM) (LEFT FRONT CORNER OF ENGINE COMPT)
DATA LINK CONNECTOR (DLC) (BELOW LEFT SIDE OF DASH)
DIFFERENTIAL ELECTRONIC MODULE (AT REAR DIFFERENTIAL)
DRIVER DOOR MODULE (DDM)
FUSE FUSE BOX (AT LEFT END OF DASH)
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
LIGHTS SWITCH UNIT (LSM)
NCA WIRE
OCCUPANT WEIGHT SENSOR (OWS) (UNDER FRONT PASSENGER'S SEAT)
PASSENGER COMPARTMENT)
PNK PNK WIRE
PNK WIRE
RED WIRE
SIREN CONTROL MODULE (SCM) (IN RIGHT FRONT WHEELWELL)
STEERING ANGLE SENSOR MODULE
STEERING WHEEL MODULE (SWM)
SUNROOF CONTROL MODULE (SRM) (FORWARD OF SUN ROOF OPENING)
SUPPLEMENTAL RESTRAINT SYSTEM CONTROL MODULE (SRS) (BELOW FLOOR CONSOLE,
SUSPENSION MODULE (SUM) (FOUR-C) (UNDER CENTER CONSOLE)
UPPER ELECTRONIC MODULE (UEM) (INTEGRAL TO REARVIEW MIRROR)
W/O SUNROOF
WHT WIRE
Computer data lines circuit (2 of 2)
ACCESSORY ELECTRONIC MODULE (AEM) (AT RIGHT REAR CORNER OF CARGO COMPT)
AIR QUALITY SENSOR (AQS) (AT RIGHT SIDE OF PLENUM)
AUDIO MODULE (AUM) (UNDER RIGHT FRONT SEAT)
AUTOMATIC TRANSMISSION MODE SELECTOR
CLIMATE CONTROL MODULE (CCM)
DAMPER MOTOR MODULE (DMM) (ON HVAC HOUSING)
DAMPER MOTOR MODULE (ON HVAC HOUSING)
DRIVER INFORMATION MODULE (DIM)
ELECTRONIC THROTTLE MODUEL (ETM) (GASOLINE) (ON LEFT SIDE OF ENGINE)
GEAR SELECTOR MODULE (GSM)
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRN/YEL WIRE
INCLINATION SENSOR MODULE (ISM) (LEFT REAR CORNER OF CARGO COMPT)
LEFT SEAT HEATER MODULE (SHM) (UNDER LEFT FRONT SEAT)
NCA WIRE
PARKING ASSISTANCE MODULE (PAM) (AT LEFT REAR CORNER OF CARGO COMPT)
PASSENGER DOOR MODULE (PDM)
PHONE MODULE (PHM)
POWER SEAT MODULE (PSM) (UNDER DRIVER'S SEAT)
REAR ELECTRONIC MODULE (REM) (AT LEFT REAR CORNER OF CARGO COMPT)
RIGHT SEAT HEATER MODULE (SHM) (UNDER RIGHT FRONT SEAT)
ROAD TRAFFIC INFORMATION (RTI) (LEFT REAR CORNER OF CARGO COMPT)
WHT WIRE
YEL WIRE
YEL/GRN WIRE
