Back-up lamps circuit for Volvo V70 I (1997-2000)
Back-up lamps circuit
A/T
BACK UP LAMP
BACK-UP LIGHT SWITCH (ON TRANSAXLE)
BLK WIRE
BLU WIRE
CENTRAL ELECTRICAL
ENG COMPT)
EXTERIOR LIGHTS CIRCUIT
FUSE
GEAR POSITION SWITCH (ON TRANSAXLE)
GRY WIRE
HOT W/ OVERLOAD RELAY 106 ENERGIZED
LEFT LOWER TAILLAMP UNIT BACK- UP LAMP
LEFT TAILLAMP UNIT BACK- UP LAMP
M/T
NCA WIRE
RIGHT LOWER TAILLAMP UNIT
RIGHT TAILLAMP UNIT
UNIT (LEFT REAR OF
