Volvo V70 I (1997-2000) tailgate wiper intermittent relay Wiring diagram
This page shows the only wiring diagram for the component.tailgate wiper intermittent relay, which is found in the car Volvo V70 I (1997-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tailgate wiper intermittent relay (1 of 1)
1999 ONLY
BLK WIRE
CENTRAL ELECTRICAL UNIT
CENTRAL ELECTRICAL UNIT (LEFT REAR OF ENG COMPT)
FUSE
GRN WIRE
GRN/GRY WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
HOT IN ACC OR RUN
INT WIPE
LEFT FRONT STRUT TOWER)
NCA WIRE
ORG/BLK WIRE
POWER GROUND CONNECTOR
SIGNAL GROUND CONNECTOR
SOLID STATE
TAILGATE WASHER MOTOR
TAILGATE WIPER INTERMITTENT RELAY
TAILGATE WIPER MOTOR
TAILGATE WIPER/WASHER SWITCH
VIO WIRE
WASHER SWITCH
WHT WIRE
WIPE
WIPER/WASHER SWITCH
X-RAIL CONNECTOR
YEL WIRE
YEL/VIO WIRE
Go to component -> Rear wiper/washer circuit -> TAILGATE WIPER INTERMITTENT RELAY
