Volvo V70 I (1997-2000) rec ctrl rec ctrl rec ctrl rec ctrl rec ctrl ignition Wiring diagram

2.3L, 2.4L TURBO 2.4L ENGINE A/C PRESSURE SENSOR (ON RIGHT FRONT OF ENGINE COMPARTMENT) A/C PRESSURE SWITCH (PRESSOSTAT) (ON RIGHT REAR OF ENGINE COMPARTMENT) A/C RELAY (ON ENGINE COMPARTMENT RELAY/FUSE BOX, POSITION NO 4) A/C SWITCH SOLENOID (ON A/C COMPRESSOR) ALTERNATIVE MODEL BASE MODEL BASE MODEL ONLY BLK WIRE BLOWER FAN (BEHIND RIGHT SIDE OF DASH, ON HVAC HOUSING) BLOWER FAN RESISTOR (ON RIGHT SIDE OF HVAC HOUSING) BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/GRY WIRE BRN/ORG WIRE BRN/PNK WIRE BRN/WHT WIRE CENTRAL ELECTRICAL UNIT (ON LEFT REAR OF ENGINE COMPARTMENT) CLIMATE CONTROL SYSTEM DATA LINK CONNECTOR (DLC) (ON CENTER CONSOLE, REAR OF SHIFT LEVER) ENGINE COOLANT FAN ENGINE COOLANT FAN (FC) RELAY (ON TOP RIGHT OF RADIATOR SHROUD) ENGINE COOLANT TEMPERATURE (ECT) SENSOR (ON LEFT FRONT OF ENGINE) FLOOR, DEFROSTER, VENTILATION SHUTTER SERVO MOTOR (ON LEFT SIDE OF HVAC HOUSING) FUSE 1 FUSE 31 FUSE 5 GRN WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE GRY/ORG WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START MODE CTRL MODE CTRL MODE CTRL MODE CTRL MODE CTRL ILLUM BATTERY ILLUM NCA WIRE ORG/ WIRE PNK 3 WIRE PNK INTERIOR LIGHTS SYSTEM (RHEOSTAT) WIRE PNK WIRE REC CTRL REC CTRL REC CTRL REC CTRL REC CTRL REC CTRL IGNITION RECIRCULATION SHUTTER SERVO MOTOR (ON RIGHT SIDE OF HVAC HOUSING) RED WIRE SOLID STATE VIO WIRE VIO/WHT WIRE WHT WIRE YEL WIRE YEL/GRY WIRE YEL/RED WIRE YEL/VIO WIRE YEL/WHT WIRE
