Volvo V70 I (1997-2000) base model only Wiring diagrams
This page contains all the electrical diagrams for the component. base model only, in which he is found in the car Volvo V70 I (1997-2000). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram base model only (1 of 2)
ALARM/IMMOBILIZER ECC SUN SENSOR, LED INDICATOR (ON TOP CENTER OF DASH)
ALTERNATIVE MODEL
ANTI-THEFT SYSTEM
BASE MODEL
BASE MODEL ONLY
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
CABIN TEMPERATURE SENSOR (BEHIND CENTER OF DASH)
ENGINE COMPARTMENT TEMPERATURE (ECT) SENSOR (ON LEFT FRONT OF ENGINE)
ENGINE COOLANT FAN
ENGINE COOLANT FAN (FC) RELAY (ON TOP RIGHT OF RADIATOR SHROUD)
FLOOR, DEFROSTER, VENTILATION SHUTTER SERVO MOTOR (ON LEFT SIDE OF HVAC HOUSING)
FUSE 1
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
OUTSIDE TEMPERATURE SENSOR (ECC) (ON RIGHT SIDE OF HVAC HOUSING)
PNK WIRE
PNK/WHT WIRE
RED WIRE
TEMPERATURE SHUTTER SERVO MOTOR (RIGHT) (ON CENTER OF HVAC HOUSING)
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRY WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> A/c circuit, auto a/c (2 of 2) -> BASE MODEL ONLY
Wiring diagram base model only (2 of 2)
2.3L, 2.4L TURBO 2.4L ENGINE
A/C PRESSURE SENSOR (ON RIGHT FRONT OF ENGINE COMPARTMENT)
A/C PRESSURE SWITCH (PRESSOSTAT) (ON RIGHT REAR OF ENGINE COMPARTMENT)
A/C RELAY (ON ENGINE COMPARTMENT RELAY/FUSE BOX, POSITION NO 4)
A/C SWITCH SOLENOID (ON A/C COMPRESSOR)
ALTERNATIVE MODEL
BASE MODEL
BASE MODEL ONLY
BLK WIRE
BLOWER FAN (BEHIND RIGHT SIDE OF DASH, ON HVAC HOUSING)
BLOWER FAN RESISTOR (ON RIGHT SIDE OF HVAC HOUSING)
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRY WIRE
BRN/ORG WIRE
BRN/PNK WIRE
BRN/WHT WIRE
CENTRAL ELECTRICAL UNIT (ON LEFT REAR OF ENGINE COMPARTMENT)
CLIMATE CONTROL SYSTEM
DATA LINK CONNECTOR (DLC) (ON CENTER CONSOLE, REAR OF SHIFT LEVER)
ENGINE COOLANT FAN
ENGINE COOLANT FAN (FC) RELAY (ON TOP RIGHT OF RADIATOR SHROUD)
ENGINE COOLANT TEMPERATURE (ECT) SENSOR (ON LEFT FRONT OF ENGINE)
FLOOR, DEFROSTER, VENTILATION SHUTTER SERVO MOTOR (ON LEFT SIDE OF HVAC HOUSING)
FUSE 1
FUSE 31
FUSE 5
GRN WIRE
GRN/BRN WIRE
GRN/GRY WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
MODE CTRL MODE CTRL MODE CTRL MODE CTRL MODE CTRL ILLUM BATTERY ILLUM
NCA WIRE
ORG/ WIRE
PNK 3 WIRE
PNK INTERIOR LIGHTS SYSTEM (RHEOSTAT) WIRE
PNK WIRE
REC CTRL
REC CTRL REC CTRL REC CTRL REC CTRL REC CTRL IGNITION
RECIRCULATION SHUTTER SERVO MOTOR (ON RIGHT SIDE OF HVAC HOUSING)
RED WIRE
SOLID STATE
VIO WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
YEL/GRY WIRE
YEL/RED WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> A/c circuit, manual a/c -> BASE MODEL ONLY
