Volvo V60 Cross Country I (2014-2018) steering column lock module Wiring diagram
This page shows the only wiring diagram for the component.steering column lock module, which is found in the car Volvo V60 Cross Country I (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering column lock module (1 of 1)
2.5L TURBO/3.0L TURBO 2.0L TURBO
74/301
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
CENTRAL ELECTRONIC MODULE
CENTRAL ELECTRONIC MODULE (CEM)
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL MODULE (ECM)
GRN/BLK WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
IGNITION SWITCH
IMMOBILIZER ANTENNA UNIT
RED/BLK WIRE
RED/BLU WIRE
RED/VIO WIRE
RIGHT END OF DASH)
STEERING COLUMN LOCK MODULE
STEERING COLUMN LOCK RELAY
VIO/BRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
WHT WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Starting circuit, w/o start-stop system (2 of 2) -> STEERING COLUMN LOCK MODULE
