Volvo V60 Cross Country I (2014-2018) intake side camshaft position sensor Wiring diagram
This page shows the only wiring diagram for the component.intake side camshaft position sensor, which is found in the car Volvo V60 Cross Country I (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram intake side camshaft position sensor (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
COOLANT TEMPERATURE SENSOR
ENGINE CONTROL MODULE (ECM)
FRONT KNOCK SENSOR
FUEL LINE PRESSURE SENSOR
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/ORG WIRE
GRY/VIO WIRE
INTAKE SIDE CAMSHAFT POSITION SENSOR
MASS AIRFLOW SENSOR (MAF)
OIL PRESSURE/ TEMPERATURE SENSOR
ORG/BLU WIRE
OUTLET SIDE CAMSHAFT POSITION SENSOR
REAR OXYGEN SENSOR
THROTTLE UNIT
VIO WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 2.0l turbo (6 of 6) -> INTAKE SIDE CAMSHAFT POSITION SENSOR
