Exterior lamps circuit for Volvo V40 I facelift (1999-2004)

AUXILIARY BRAKE LIGHT BLK WIRE BLU WIRE BLU/PNK WIRE BLU/RED WIRE BLU/YEL WIRE BRAKE LIGHTS/ UNLOCKING SELECTOR LEVER SWITCH BRN WIRE BRN/BLK WIRE BRN/WHT WIRE CENTRAL ELECTRIC MODULE (CEM) (BEHIND LEFT END OF DASH) ENGINE COMPARTMENT FUSE, RELAY BOX (LEFT REAR CORNER OF ENGINE COMPT) FUSE 13 FUSE 23 FUSE 24 FUSE 4 FUSE 6 FUSE 7 GRN WIRE GRY WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT IN HOT IN RUN OR START LEFT BRAKE LIGHT LEFT FRONT DIRECTION INDICATOR LEFT FRONT PARK LIGHT LEFT FRONT PARKING LIGHT/ DIRECTION INDICATOR LAMP HOUSING LEFT FRONT SIDE MARKER LAMP LEFT REAR LAMP HOUS- ING LEFT REAR PARK LIGHT LIGHTS SWITCH UNIT ONLY PASSENGER COMPARTMENT FUSE, RELAY BOX (BEHIND LEFT END OF DASH) PNK WIRE PNK/BLK WIRE RED WIRE RIGHT BRAKE LIGHT RIGHT FRONT DIRECTION INDICATOR RIGHT FRONT PARK LIGHT RIGHT FRONT PARKING LIGHT/ DIRECTION INDICATOR LAMP HOUSING RIGHT FRONT SIDE MARKER LAMP RIGHT REAR LAMP HOUS- ING RIGHT REAR PARK LIGHT RUN WIRE SHIFT INTERLOCK SYSTEM TRANSMISSION SYSTEM VIO WIRE WHT WIRE YEL WIRE YEL/BRN WIRE

BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/ORG WIRE BRN/WHT WIRE BULB MALFUNCTION INDICATOR COMBINED INSTRUMENT PANEL DIREC- TION INDICATOR LAMP DIREC- TION INDICATOR LAMP DIRECTION INDICATOR RELAY FUSE 11 FUSE 6 FUSE 8 GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE GRN/YEL WIRE HAZARD WARNING FLASHER SWITCH HOT AT ALL TIMES HOT IN RUN HOT IN RUN OR START LEFT LICENSE PLATE LAMP RIGHT LICENSE PLATE LAMP LEFT REAR DIRECTION INDICATOR LAMP LEFT REAR LAMP HOUS- ING LEFT REAR LAMP HOUSING RIGHT REAR LAMP HOUSING LEFT REAR SIDE MARKER LIGHT LEFT TAIL LIGHT LEFT TURN INDICATOR ONLY PASSENGER COMPARTMENT FUSE, RELAY BOX (BEHIND LEFT END OF DASH) RED WIRE RIGHT REAR DIRECTION INDICATOR LAMP RIGHT REAR LAMP HOUS- ING RIGHT REAR LAMP HOUSING RIGHT REAR SIDE MARKER LIGHT RIGHT TAIL LIGHT RIGHT TURN INDICATOR TRAILER INDICATOR TRUNK LID/ TAILGATE LAMP HOUSING TURN SIGNAL/ HIGH-LOW BEAM SWITCH VGLA CONTROL MODULE (BEHIND LOWER CENTER OF DASH) WARNING/ INDICATOR YEL WIRE YEL/BRN WIRE
