Volvo S80 II facelift (2009-2013) Starting circuit

15- FEED RELAY ALTERNATOR BATTERY BATTERY FUSES BLK WIRE BLU WIRE BRN WIRE ENGINE COMPARTMENT DISTRIBUTION BOX FUSE GRN WIRE GRN/RED WIRE GRN/VIO WIRE GRY WIRE GRY/BLK WIRE NCA WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE STARTER MOTOR STARTER MOTOR RELAY VIO WIRE VIO/BRN WIRE WHT WIRE YEL WIRE

22 10 18 74/301 3 2 1 74/413 32 74/301 74/413 BLK WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE CENTRAL ELECTRONIC MODULE CENTRAL ELECTRONIC MODULE (BEHIND ENGINE CONTROL MODULE (ECM) (LEFT REAR OF ENGINE COMPT) FUSE GRN/RED WIRE GRN/VIO WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE RED/BLK WIRE RED/BLU WIRE RED/VIO WIRE RIGHT END OF DASH) START CONTROL MODULE (SCU) (LEFT SIDE OF DASH) STEERING COLUMN LOCK MODULE (ON STEERING COLUMN) STEERING COLUMN LOCK RELAY VIO/BRN WIRE VIO/ORG WIRE WHT WIRE YEL WIRE YEL/BLU WIRE
