Volvo S80 II facelift (2009-2013) Charging circuit

ALTERNATOR BATTERY BATTERY FUSES FUSE BLK WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER INFORMATION MODULE (DIM) (LEFT SIDE OF DASH) ENGINE CONTROL MODULE (LEFT REAR OF ENGINE COMPT) GRN/BLK WIRE GRY/ORG WIRE NCA WIRE RED WIRE STARTER MOTOR STARTING CIRCUIT VIO/ORG WIRE
