Radio circuit, premium for Volvo S80 II facelift (2009-2013)

1 2 3 4 5 6 7 8 9 10 11 12 13 LF- CS- RF- LR- RR- 22 74/507 22 74/508 3 74/509 3 74/510 6 14 2 1 3 74/503 7 74/403 9 10 11 12 13 74/407 9 74/409 AUDIO MODULE (UNDER FRONT PASSENGER'S SEAT) BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BLU WIRE BLU/ORG WIRE BLU/RED WIRE CENTER DASHBOARD SPEAKER CENTRAL ELECTRONIC MODULE (CEM) (BEHIND RIGHT END OF DASH) FUSE G-INFOT (RIGHT REAR CORNER OF LUGGAGE COMPT) GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/VIO WIRE GRY WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES LEFT FRONT DOOR SPEAKER LEFT FRONT TWEETER LEFT REAR DOOR SPEAKER LEFT REAR DOOR TWEETER LF+ CS+ RF+ LR+ RR+ MOST DATA BUS CIRCUIT ORG/ WIRE PASSENGER COMPARTMENT DISTRIBUTION BOX REAR HEADPHONES SOCKETS RED WIRE RIGHT FRONT DOOR SPEAKER RIGHT FRONT TWEETER RIGHT REAR DOOR SPEAKER RIGHT REAR DOOR TWEETER SUBWOOFER MODULE VIO/BLK WIRE VIO/RED WIRE WHT WIRE WHT/ORG WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/RED WIRE YEL/VIO WIRE

1 2 3 4 5 74/420 4 1 2 3 74/403 6 21 74/401 74/405 74/409 74/412 AUXILIARY EQUIPMENT INPUT BLK WIRE BLU WIRE BRN WIRE CELLULAR PHONE HANDSFREE CONTROL MODULE COMPUTER DATA LINES SYSTEM DATA FUSE GRN WIRE GRN/ORG WIRE GRN/VIO WIRE GRY/ORG WIRE GRY/YEL WIRE HOT AT ALL TIMES INFOTAINMENT CONTROL MODULE INTEGRATED AUDIO MODULE MICROPHONE (IN OVERHEAD CONSOLE) MOST DATA BUS CIRCUIT NCA WIRE ORG/ WIRE PASSENGER COMPARTMENT DISTRIBUTION BOX RED WIRE RIGHT REAR WINDOW ANTENNA SHIELD SOLID STATE STEERING WHEEL MODULE (SWM) (IN STEERING COLUMN) USB PORT V-BUS VIO/ORG WIRE WHT WIRE WINDOW ANTENNA AMPLIFIER (AT LEFT "C" PILLAR) YEL/RED WIRE
