Volvo S80 II facelift (2009-2013) tilt vspeed comf feed fwd bwd gnd Wiring diagram
This page shows the only wiring diagram for the component.tilt vspeed comf feed fwd bwd gnd, which is found in the car Volvo S80 II facelift (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tilt vspeed comf feed fwd bwd gnd (1 of 1)
1 2 3 4 5 6 7 8 9 10 VBAT GLOBAL CLOSE
74/414
74/504
BLK WIRE
BLK/WHT WIRE
BLU/BLK WIRE
BLU/GRY WIRE
CEILING LIGHT SWITCH UNIT
CEM
COMFORT FUNCTIONS RELAY
FUSE
HOT AT ALL TIMES
HOT AT ALL TIMES CENTRAL ELECTRONIC MODULE (CEM) (BEHIND RIGHT END OF DASH)
ORG/ WIRE
PASSENGER COMPARTMENT DISTRIBUTION BOX
POWER SUNROOF SWITCH
RED WIRE
RED/BRN WIRE
SUNROOF CONTROL MODULE (FORWARD OF SUNROOF OPENING)
TILT VSPEED COMF FEED FWD BWD GND
VIO/BRN WIRE
VIO/GRN WIRE
VIO/WHT WIRE
WHT WIRE
YEL/ORG WIRE
Go to component -> Power top/sunroof circuit -> TILT VSPEED COMF FEED FWD BWD GND
