Volvo S80 II facelift (2009-2013) spark plug w/ ignition coils, capacitor Wiring diagram
This page shows the only wiring diagram for the component.spark plug w/ ignition coils, capacitor, which is found in the car Volvo S80 II facelift (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram spark plug w/ ignition coils, capacitor (1 of 1)
BATTERY
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BRAKE CONTROL MODULE
BRAKE LIGHT DIAGNOSTIC CONTACT, ACCELERATOR PEDAL SENSOR
CENTRAL ELECTRONIC MODULE
COOLING FAN CONTROL MODULE
FUEL PUMP, FUEL PUMP CONTROL MODULE
G-AL (RIGHT FRONT OF ENGINE COMPT)
G-INFOT (RIGHT REAR CORNER OF LUGGAGE COMPT)
G-TRM (LEFT REAR CORNER OF LUGGAGE COMPT)
HEADLAMP CONTROL MODULE (HCM), BRAKE FLUID LEVEL SENSOR, SIREN CONTROL MODULE
LEFT VANITY MIRROR LIGHTING, REAR READING LIGHT, DATA LINK CONNECTOR
LICENSE PLATE LIGHTING
PARK BRAKE MODULE (PBM), TRUNK HANDLE SWITCH
PTC ELEMENT
REFRIGERATION BOX RELAY, REFRIGERATION BOX, CARGO COMPARTMENT
RIGHT FRONT AUXILIARY LIGHT, LEFT FRONT AUXILIARY LIGHT
RIGHT FRONT LAMP HOUSING, RIGHT FRONT FOG LIGHT, HORN 1, HORN 2
RIGHT REAR LAMP HOUSING, REFRIGERATION BOX,
SPARK PLUG W/ IGNITION COILS
SPARK PLUG W/ IGNITION COILS, CAPACITOR
SPARK PLUG W/ IGNITION COILS, CAPACITOR (3.2L)
TRUNK LID CENTRAL LOCK
WHT WIRE
WIPER MOTOR MODULE
Go to component -> Ground distribution circuit -> SPARK PLUG W/ IGNITION COILS, CAPACITOR
