Volvo S80 II facelift (2009-2013) rear adjustable head restraint switch Wiring diagram
This page shows the only wiring diagram for the component.rear adjustable head restraint switch, which is found in the car Volvo S80 II facelift (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear adjustable head restraint switch (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CEM
CENTRAL ELECTRONIC MODULE (CEM)
CLIMATE CONTROL
COMPUTER DATA LINES SYSTEM
FUSE
GRN WIRE
GRY WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
LEFT REAR HEADREST RESTRAINT SOLENOID (IN LEFT REAR SEAT HEADREST)
MODULE (CENTER OF DASH)
NCA WIRE
ORG/ WIRE
PASSENGER COMPARTMENT DISTRIBUTION BOX
REAR ADJUSTABLE HEAD RESTRAINT RELAY
REAR ADJUSTABLE HEAD RESTRAINT SWITCH
RED WIRE
RIGHT REAR HEADREST RESTRAINT SOLENOID (IN RIGHT REAR SEAT HEADREST)
VIO WIRE
VIO/ORG WIRE
WHT WIRE
WHT/RED WIRE
Go to component -> Rear head restraint circuit -> REAR ADJUSTABLE HEAD RESTRAINT SWITCH
