Volvo S80 II facelift (2009-2013) power passenger seat switch unit Wiring diagram
This page shows the only wiring diagram for the component.power passenger seat switch unit, which is found in the car Volvo S80 II facelift (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power passenger seat switch unit (1 of 1)
16 74/31
74/31
BACKREST SWITCH
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BRN WIRE
CEM
CENTRAL ELECTRONIC MODULE (CEM) (BEHIND RIGHT END OF DASH)
DOWN
FORW
FORW BACK
FORWARD/ BACKWARD SWITCH
FRONT EDGE UP/DOWN SWITCH
FUSE
GRY WIRE
HOT AT ALL TIMES
ORG/ WIRE
ORG/BLU WIRE
PASSENGER BACKREST ANGLE SEAT MOTOR (IN PASSENGER SEAT BACK)
PASSENGER COMPARTMENT FUSE DISTRIBUTION BOX
PASSENGER FORWARD/ BACKWARD SEAT MOTOR (IN FRONT PASSENGER SEAT)
PASSENGER UP/DOWN FRONT EDGE SEAT MOTOR (IN PASSENGER SEAT BOTTOM)
PASSENGER UP/DOWN REAR EDGE SEAT MOTOR (IN PASSENGER SEAT BOTTOM)
POWER PASSENGER SEAT SWITCH UNIT
REAR EDGE UP/DOWN SWITCH
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
SEAT HEATING MODULE/INTERIOR LIGHTING RELAY
STOP LOGIC
UP BACK
UP DOWN
WHT WIRE
WHT/BLK WIRE
Go to component -> Passenger"s power seat circuit -> POWER PASSENGER SEAT SWITCH UNIT
