Volvo S80 II facelift (2009-2013) passenger's door switch central locking system Wiring diagram

20 74/507 3 74/507 3 74/508 74/501 74/509 74/510 74/601 AJAR BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/VIO WIRE BLU WIRE BLU/BLK WIRE BLU/GRY WIRE BLU/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR MODULE (DDM) (IN DRIVER FRONT DOOR) EXECUTIVE FUSE GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/RED WIRE GRN/VIO WIRE GRY WIRE GRY/BLK WIRE GRY/ORG WIRE HOT W/ 15 FEED RELAY ENERGIZED HOT W/ COMFORT FUNCTIONS RELAY ENERGIZED LEFT CARGO COMPARTMENT LIGHT ORG/ WIRE PASSENGER COMPARTMENT DISTRIBUTION BOX PASSENGER DOOR MODULE (PDM) (IN PASSENGER FRONT DOOR) PASSENGER'S DOOR SWITCH CENTRAL LOCKING SYSTEM PNK PNK WIRE PNK WIRE REAR LEFT ARMREST COOLER LIGHTING COMPARTMENT CENTER 1 LIGHTING REAR RIGHT COOLER COMPARTMENT ARMREST LIGHTING CENTER 2 LIGHTING RED WIRE RIGHT CARGO COMPARTMENT LIGHT RIGHT FRONT CENTRAL LOCKING LOCK MOTOR (REAR OF RIGHT FRONT DOOR) RIGHT FRONT DOOR COMPARTMENT LIGHTING (EXECUTIVE) RIGHT FRONT DOOR HANDLE LIGHTING TRUNK LID CENTRAL LOCKING MOTOR (CENTER REAR OF TRUNK LID) VIO WIRE VIO/ORG WIRE VIO/RED WIRE W/ KEYLESS ENTRY W/ SUNROOF WHT WIRE YEL WIRE
