Volvo S80 II facelift (2009-2013) passenger power seat switch unit Wiring diagram
This page shows the only wiring diagram for the component.passenger power seat switch unit, which is found in the car Volvo S80 II facelift (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger power seat switch unit (1 of 1)
74/30
74/31
74/535
AJAR
BLK WIRE
BLK/GRN WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
DRIVER'S DOOR CENTRAL LOCKING SYSTEM SWITCH
DRIVER'S DOOR SILL CONVERTER/CONTROL MODULE (UNDER DRIVER FRONT DOOR SILL)
EXECUTIVE
FRONT DRIVER'S SIDE SILL LIGHTING
FRONT PASSENGER'S SIDE SILL LIGHTING
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY/BLK WIRE
GRY/ORG WIRE
LEFT FRONT DOOR HANDLE LIGHTING
LEFT REAR DOOR HANDLE LIGHTING
ORG/ WIRE
PASSENGER POWER SEAT SWITCH UNIT
POWER SEAT MODULE (PSM) (LEFT SIDE OF DRIVER'S SEAT CUSHION)
REAR DRIVER'S SIDE SILL LIGHTING
REAR PASSENGER'S SIDE SILL LIGHTING
RED WIRE
RED/WHT WIRE
RIGHT FRONT COURTESY LIGHT
RIGHT REAR DOOR HANDLE LIGHTING
RIGHT REAR LIGHTING DOOR COMPARTMENT (EXECUTIVE)
VIO WIRE
VIO/GRN WIRE
VIO/RED WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (3 of 3) -> PASSENGER POWER SEAT SWITCH UNIT
